Acer | X1228HN | XGA (1024x768) | 4800 ANSI lumens | Black
Acer | X1228HN | XGA (1024x768) | 4800 ANSI lumens | Black
Sign up and unlock up to 10% off!
- Characteristics
- Projection modes: Front, Rear, Ceiling
- Interactive: No
- Design
- Market positioning: Portable
- Product Type: Standard Throw Projector
- Product color: Black
- Intended use: Ceiling
- Power
- Power consumption (economy mode): 205 W
- Power consumption in standby mode: 0.5 W
- Power consumption: 275 W
- AC input voltage: 100 - 240 V
- Power source: AC
- Weight and dimensions
- Product height: 113.7 mm
- Product weight: 2.8 kg
- Product width: 313 mm
- Product depth: 240 mm
- Network
- Smart TV: No
- Wired LAN: Yes
- Wi-Fi: No
- Number of Ethernet LAN ports (RJ-45): 1
- Package contents
- Remote control included: Yes
- Suitcase: Yes
- Batteries included: Yes
- AC adapter: Yes
- Wires
- Alternating current
- VGA
- Display
- Built-in display: No
- Multimedia
- Built-in speakers: Yes
- Number of built-in speakers: 1
- Output power (RMS): 3 W
- Data carrier
- Integrated card reader: No
- Ports and interfaces
- Audio output (right/left): 1
- SCSI interface: RS-232
- Audio Input (L,R): 1
- Composite video input: 1
- Number of VGA (D-Sub) ports: 1
- DVI Port: No
- Video
- Supported graphics resolutions
- 1024 x 768 (XGA)
- 1920 x 1200 (WUXGA)
- Supported graphics resolutions
- Lens system
- Zoom type: Manual
- Focal length: 21.85 - 24.01 mm
- Zoom capability: Yes
- Zoom ratio: 1.1:1
- Lens range: 2.41 - 2.53
- Focus: Manual
- Offset: 130%
- Incidence ratio: 1.94 - 2.16
- Safety warning
- Warnings
- Avoid placing the projector in high humidity areas to prevent damage to the device.
- Do not look directly into the projector lens while it is operating to avoid eye damage.
- Be careful when replacing the projector lamp as it can be very hot.
- Warnings
- Projector
- Projector native resolution: XGA (1024x768)
- Projector brightness: 4800 ANSI lumens
- Projection technology: DLP
- Projector brightness (economy mode): 3840 ANSI lumens
- Supported aspect ratio: 16:9
- Screen size compatibility: 584.2 - 7620 mm (23 - 300")
- Contrast ratio (typical): 20000:1
- Scanning range (length): 24 - 120 Hz
- Native aspect ratio: 4:3
- Horizontal scanning range: 15 - 100 kHz
- Light source
- Lamp power: 220 W
- Number of lamps: 1
- Light source type: Lamp
