CHIEFTEC POWER SUPPLY VALUE SERIES APB-700B8 700W
CHIEFTEC POWER SUPPLY VALUE SERIES APB-700B8 700W
CHIEFTEC POWER SUPPLY VALUE SERIES APB-700B8 700W
PRICE:
71,99
€
IN A WAREHOUSE
6 pcs
We'll ship this product in 3 days.
FREE EUROPE SHIPPING FROM 149 €!
30 DAYS FOR A RETURN!
Sign up and unlock up to 10% off!
- Technical details
- Sustainability: Yes
- Design
- Number of fans: 1 fan
- Cooling type: Active
- Fan bowl diameter: 12 cm
- Product color: Silver
- Power
- Maximum output current (+5V): 22A
- Total power (+12V): 648 W
- AC input voltage: 200 - 240 V
- Total power: 700 W
- AC input frequency: 47 - 63 Hz
- Power factor: 0.9
- Maximum output current (+3.3V): 22 A
- Maximum output current (+12 V1): 54 A
- PFC (Power Factor Correction) Type: Active
- Total power (+5V): 130 W
- Input current: 5 A
- Power protection features
- Protection against overvoltage
- Voltage surge protection
- Short circuit
- Overheating protection
- Low voltage protection
- Overload
- Total power (+3.3V): 130 W
- Weight and dimensions
- Product depth: 140 mm
- Product width: 150 mm
- Product height: 87 mm
- Product weight: 1.42 kg
- Efficiency
- ATX version: 2.3
- Power supply type (PSU): ATX
- 80 PLUS Certificate: 80 PLUS
- Intended use: PC/server
- Packaging data
- Weight with packaging: 1.57 kg
- Certificates
- Certificates of conformity: CE
- Ports and interfaces
- EPS power connector (4+4 pin): Yes
- CPU power supply connector (4+4 pin): Yes
- PCI Express power cable length: 50 cm
- CPU power cable length: 50 cm
- Motherboard power connector: 20+4 pin ATX
- Number of SATA power connectors: 4
- Motherboard cable length: 55 cm
- SATA power cable length
- 550
- 150
- Floppy drive connector: 1
- Peripheral (Molex) Power Cable Length
- 500 mm
- 150
- Floppy disk drive slot: Yes
- PCI Express power connectors (6+2 pin): 2
- Wiring Type: Non-Modular
- Peripheral (Molex) Power Connectors (4-pin): 2
- Logistics data
- Harmonized System (HS) code: 84733020
| Name | Details |
|---|---|
| Category | Computers and accessories |
| Producer | Chieftec |
| Department | Electronics |
