Chieftec Smart Series 500W GPF-500G power supply
Chieftec Smart Series 500W GPF-500G power supply
Chieftec Smart Series 500W GPF-500G power supply
PRICE:
93,99
€
IN A WAREHOUSE
5 pcs
We'll ship this product in 2 days.
FREE EUROPE SHIPPING FROM 149 €!
30 DAYS FOR A RETURN!
Sign up and unlock up to 10% off!
- Design
- Fan bowl diameter: 8 cm
- Cooling type: Active
- Product color: Black
- Power
- Maximum output current (+3.3V): 18 A
- Total power (-12V): 3.6 W
- Maximum output current (+5V): 18A
- Total power: 500 W
- Maximum output current (+5 Vsb): 2.5 A
- Total power (+5 Vsb): 12.5 W
- Maximum output current (+12V): 41.6A
- Maximum output current (-12V): 0.3A
- Power protection features
- Low voltage protection
- Overload
- Short circuit
- Overheating protection
- Protection against overvoltage
- Overcurrent
- AC input voltage: 100 - 240 V
- AC input frequency: 47 - 63 Hz
- Input current: 8 A
- Weight and dimensions
- Product width: 85 mm
- Product height: 65 mm
- Product depth: 175 mm
- Product weight: 1.42 kg
- Efficiency
- ATX version: 2.4
- 80 PLUS Certificate: 80 PLUS Gold
- Intended use: PC
- Power supply unit (PSU) type: TFX
- Packaging data
- Weight with packaging: 1.55 kg
- Ports and interfaces
- Number of SATA power connectors: 4
- Wiring Type: Non-Modular
- Peripheral (Molex) Power Cable Length
- 350
- 150 mm
- Motherboard power connector: 24-pin ATX
- SATA power cable length
- 350
- 150 mm
- Floppy drive cable length: 15 cm
- Motherboard cable length: 40 cm
- Floppy drive connector: 1
- Floppy disk drive slot: Yes
- Peripheral (Molex) Power Connectors (4-pin): 2
| Name | Details |
|---|---|
| Producer | Chieftec |
