Chieftec Task TPS-500S 500 W power supply module 24-pin ATX ATX Black
Chieftec Task TPS-500S 500 W power supply module 24-pin ATX ATX Black
Chieftec Task TPS-500S 500 W power supply module 24-pin ATX ATX Black
PRICE:
74,99
€
IN A WAREHOUSE
above 10 pcs
We'll ship this product in 5 days.
FREE EUROPE SHIPPING FROM 149 €!
30 DAYS FOR A RETURN!
Sign up and unlock up to 10% off!
- Design
- Fan location: Side
- Product colour: Black
- Number of fans: 1 fan
- Built-in on/off switch: Yes
- Cooling type: Active
- Fan diameter: 12 cm
- Power
- Maximum output current (+5 Vsb): 2.5 A
- Total power (+5 V): 110 W
- Maximum output current (+3.3V): 18 A
- Efficiency: 85%
- Maximum output current (+12 V1): 38 A
- Power Factor Correction (PFC) type: Active
- Maximum output current (+5 V): 17 A
- Total power (+3.3 V): 110 W
- AC input frequency: 47 - 63 Hz
- AC input voltage: 115 - 230 V
- Power protection features
- Overcharging
- Overvoltage protection
- Short circuit
- Overload protection
- Total power: 500 W
- Weight and dimensions
- Product width: 150 mm
- Product height: 86 mm
- Product depth: 140 mm
- Performance
- Power supply unit (PSU) type: ATX
- ATX version: 2.3
- Purpose: PC
- 80 PLUS certification: 80 PLUS Bronze
- Certificates
- Compliance certificates: RoHS
- Ports and interfaces
- PCI Express power connectors (6+2 pin): 2
- Number of SATA power connectors: 5
- Cabling type: Non-modular
- Motherboard power connector: 24-pin ATX
- EPS power connector (4+4 pin): Yes
- Peripheral power connectors (Molex) (4-pin): 3
- Logistics data
- Harmonized System (HS) code: 84733020
| Name | Details |
|---|---|
| Category | Computers and accessories |
| Product Type | Power supplies |
| Producer | Chieftec |
| Colour | Black |
| Department | Electronics |
