CHIEFTEC VALUE Series Power Supply APB-500B8 500 W
CHIEFTEC VALUE Series Power Supply APB-500B8 500 W
CHIEFTEC VALUE Series Power Supply APB-500B8 500 W
PRICE:
49,99
€
IN A WAREHOUSE
8 pcs
We'll ship this product in 3 days.
FREE EUROPE SHIPPING FROM 149 €!
30 DAYS FOR A RETURN!
Sign up and unlock up to 10% off!
- Design
- Cooling type: Active
- Product colour: Silver
- Fan diameter: 12 cm
- Built-in on/off switch: Yes
- Number of fans: 1 fan
- Power
- Total power (-12 V): 3.6 W
- Maximum output current (+12 V2): 21 A
- Total power (+3.3 V): 130 W
- PFC (Power Factor Correction) type: Active
- Power protection features
- Short circuit
- Under-voltage protection
- Over-voltage protection
- Overload
- Efficiency: 80%
- Maximum output current (-12 V): 0.3 A
- Input current: 4 A
- Maximum output current (+5 V): 19 A
- AC input frequency: 50 Hz
- Total power: 500 W
- Total power (+5 Vsb): 12.5 W
- AC input voltage: 230 V
- Total power (+5 V): 130 W
- Power factor: 0.9
- Maximum output current (+3.3 V): 22 A
- Maximum output current (+12 V1): 24 A
- Maximum output current (+5 Vsb): 2.5 A
- Weight and dimensions
- Product height: 87 mm
- Product depth: 140 mm
- Product width: 150 mm
- Performance
- 80 PLUS certification: 80 PLUS
- Purpose: PC
- ATX version: 2.3
- Power supply unit (PSU) type: ATX
- Certificates
- Compliance certificates: RoHS
- Ports and interfaces
- Number of SATA power connectors: 3
- PCI Express power connectors (6+2 pin): 1
- Cabling type: Non-modular
- Floppy disk drive connector: Yes
- Motherboard power connector: 20+4 pin ATX
- Peripheral power connectors (Molex) (4-pin): 2
- EPS power supply connector (8-pin): No
- Logistics data
- Harmonized System (HS) code: 84733020
| Name | Details |
|---|---|
| Category | Computers and accessories |
| Product Type | Power supplies |
| Producer | Chieftec |
| Department | Electronics |
