Cooler Master X Silent Edge Platinum 1100 230V Power Supply Module 1100 W 24-pin ATX ATX Black
Cooler Master X Silent Edge Platinum 1100 230V Power Supply Module 1100 W 24-pin ATX ATX Black
Cooler Master X Silent Edge Platinum 1100 230V Power Supply Module 1100 W 24-pin ATX ATX Black
PRICE:
518,99
€
IN A WAREHOUSE
2 pcs
We'll ship this product in 8 days.
FREE EUROPE SHIPPING FROM 149 €!
30 DAYS FOR A RETURN!
Sign up and unlock up to 10% off!
- Design
- Number of fans: 0 fans
- Product color: Black
- Power
- Total power: 1100 W
- Power protection features
- Surge & inrush protection (SIP)
- Overvoltage protection
- Overcurrent
- Low voltage protection
- Overload protection
- Short circuit
- Overheating protection
- Maximum output current (+5 Vsb): 3 A
- Efficiency: 94%
- PFC (Power Factor Correction) Type: Active
- Maximum output current (+12V): 91.6A
- Maximum output current (-12V): 0.3A
- Total power (+3.3V): 120 W
- Total power (+12V): 1099.2 W
- Good Signal Power Delay Range: 100 - 150 ms
- Total power (-12V): 3.6 W
- Hold time: 16 ms
- Maximum output current (+5V): 20A
- Maximum output current (+3.3V): 20 A
- Total power (+5V): 120 W
- Total power (+5 Vsb): 15 W
- AC input frequency: 50/60 Hz
- AC input voltage: 200 - 240 V
- Input current: 6.1 A
- Weight and dimensions
- Product depth: 180 mm
- Product weight: 4.5 kg
- Product height: 86 mm
- Product width: 150 mm
- Working conditions
- Temperature range (operation): 0 - 40 °C
- Efficiency
- Intended use: PC
- ATX version: 3.1
- MTBF (Mean Time Between Failures): 100000 h
- Power supply type (PSU): ATX
- 80 PLUS Certificate: 80 PLUS Platinum
- Packaging data
- Package width: 382 mm
- Package height: 126 mm
- Weight with packaging: 5.2 kg
- Package depth: 224 mm
- Certificates
- Certificates of conformity
- cUL
- UKCA
- BSMI
- CE
- EAC
- RCM
- Federal Communications Commission (FCC)
- Central Committee
- REACH
- CCC
- Certificates of conformity
- Ports and interfaces
- PCI Express power connectors (12+4 pin): 1
- PCI Express power connectors (12+4 pin) cable length: 650 mm
- PCI Express power cable length: 55 cm
- SATA power cable length
- 500
- 800 mm
- 650
- 950
- Motherboard cable length: 65 cm
- EPS power connector (4+4 pin): Yes
- Motherboard power connector: 24-pin ATX
- PCI Express power connectors (6+2 pin): 4
- Peripheral (Molex) Power Cable Length
- 740
- 860 mm
- 620
- 500 mm
- Number of SATA power connectors: 12
- Wiring Type: Fully Modular
- EPS power supply connector (8-pin): Yes
- Peripheral (Molex) Power Connectors (4-pin): 4
- Other functions
- EPS cable length: 65 cm
- Logistics data
- Products in the main (outer) box: 2 pcs.
- Main (outer) case length: 265 mm
- Height of the standard (outer) box: 250 mm
- Collective (external) boxes per pallet: 120 pcs.
- Width of the collection box (external): 396 mm
