CUDY FS1010PG Switch, 8-Port 10/100M PoE+ 120W, 2x GbE Uplink
CUDY FS1010PG Switch, 8-Port 10/100M PoE+ 120W, 2x GbE Uplink
CUDY FS1010PG Switch, 8-Port 10/100M PoE+ 120W, 2x GbE Uplink
PRICE:
49,99
€
IN A WAREHOUSE
above 10 pcs
We'll ship this product in 3 days.
FREE EUROPE SHIPPING FROM 149 €!
30 DAYS FOR A RETURN!
Sign up and unlock up to 10% off!
- Design
- Product colour: Black
- LED indicators
- Operation
- PoE
- Power
- Link
- Housing material: Metal
- Power
- Power source: AC
- Surge protection
- 4 kV
- Yes
- AC input frequency: 50–60 Hz
- AC input voltage: 100–240 V
- Power supply included: Yes
- Weight and dimensions
- Product depth: 150 mm
- Product height: 44 mm
- Product width: 220 mm
- Operating conditions
- Operating temperature range: 0–40 °C
- Permissible relative humidity: 5–90%
- Storage temperature range: -40–70 °C
- Relative humidity range: 10–90%
- Network
- Ethernet LAN data transfer rate: 10,100 Mbit/s
- Copper Ethernet cabling technology
- 100BASE-TX
- 10BASE-T
- Half-duplex: Yes
- Flow control support: Yes
- Supported cable types
- Cat5
- Cat3
- Cat5e
- Cat4
- Full-duplex: Yes
- Communication standards
- IEEE 802.3af
- IEEE 802.3x
- IEEE 802.3az
- IEEE 802.3at
- VLAN support: Yes
- Performance
- Fanless: Yes
- MTBF (mean time between failures): 50000 h
- Plug and Play support: Yes
- Packaging content
- Cables: AC
- Ports and interfaces
- Basic switching Ethernet RJ-45 port type: Fast Ethernet (10/100)
- Number of uplink ports: 2
- Number of basic switching RJ-45 Ethernet ports: 8
- Power connector: AC input socket
- Other features
- Bandwidth: 2 Gbit/s
- Data transmission
- Forwarding rate: 1.48 Mpps
- Store-and-forward: Yes
- Address table size: 8000 entries
- Jumbo Frames compliant: Yes
- Jumbo Frames extension: 1528
- Packet buffer memory: 0.25 MB
- Power over Ethernet (PoE)
- PoE support: Yes
- Total Power over Ethernet (PoE) budget: 120 W
- Power over Ethernet (PoE) power per port: 30 W
- Number of Power over Ethernet Plus (PoE+) ports: 1
- Number of Fast Ethernet ports (PoE): 8
- Safety warning
- Warnings
- Do not open the housing or attempt to repair the device yourself.
- The product must not be disposed of with ordinary household waste. Take used electronic equipment to a disposal point in accordance with local regulations.
- Ensure that the device is adequately ventilated during operation.
- Warnings
| Name | Details |
|---|---|
| Category | Networking & Communication, Computers and accessories |
| Product Type | Network switches |
| Producer | CUDY |
| Department | Electronics |
