Cudy GS1005PTS1 Gigabit Ethernet (10/100/1000) Network Links PoE Support Black
Cudy GS1005PTS1 Gigabit Ethernet (10/100/1000) Network Links PoE Support Black
Cudy GS1005PTS1 Gigabit Ethernet (10/100/1000) Network Links PoE Support Black
PRICE:
49,99
€
IN A WAREHOUSE
3 pcs
We'll ship this product in 4 days.
FREE EUROPE SHIPPING FROM 149 €!
30 DAYS FOR A RETURN!
Sign up and unlock up to 10% off!
- Design
- Product color: Black
- LED diodes
- Power supply
- Action
- Link
- Housing material: Metal
- Rack mounting options: Yes
- Wall mountable: Yes
- Power
- AC input frequency: 50/60 Hz
- AC input voltage: 100 - 240 V
- Power consumption (max): 120 W
- Output current: 1.25 A
- Operating voltage: 52 V
- Power source: AC
- Power supply included: Yes
- Input current: 1.25 A
- Weight and dimensions
- Product width: 200 mm
- Product height: 44 mm
- Product depth: 145 mm
- Product weight: 645 g
- Security
- Password protection: Yes
- Management features
- Quality of Service (QoS) Support: Yes
- Cloud Managed: No
- Working conditions
- Temperature range (operation): 0 - 40 °C
- Permissible relative humidity: 10 - 95%
- Temperature range (storage): -40 - 70 °C
- Relative humidity range: 10 - 90%
- Network
- Communication standards
- IEEE 802.3at
- IEEE 802.3u
- IEEE 802.3
- IEEE 802.3af
- IEEE 802.3x
- IEEE 802.3ab
- IEEE 802.3z
- Data transfer speed via Ethernet LAN: 10,100,1000 Mbit/s
- Copper Ethernet cabling technology
- 1000BASE-TX
- 10BASE-T
- 100BASE-TX
- Full duplex: Yes
- VLAN support: Yes
- Flow Control Support: Yes
- Supported cable types
- Cat5
- Cat6
- Cat3
- Cat4
- Cat7
- Cat5e
- Cat6+
- Cat6a
- Cat8.1
- Cat8
- Cat6e
- Cat7e
- Half-duplex: Yes
- Communication standards
- Efficiency
- MTBF (Mean Time Between Failures): 100000 h
- Plug & Play Support: Yes
- Flash memory size: 8 MB
- No fan: Yes
- Packaging data
- Packaging depth: 190 mm
- Package height: 60 mm
- Package width: 245 mm
- Weight with packaging: 952 g
- Packaging type: Box
- Package contents
- User Manual: Yes
- Wires: Alternating Current
- Ports and interfaces
- Basic Ethernet switching RJ-45 ports type: Gigabit Ethernet (10/100/1000)
- Basic RJ-45 Switching Number of Ethernet Ports: 5
- Number of SFP Module slots: 1
- Power Connector: AC Input Socket
- Number of connection ports: 1
- Other functions
- Warranty period: 1 year(s)
- Logistics data
- Country of origin: China
- Products in the main (outer) box: 20 pcs.
- Width of the collection box (external): 505 mm
- Net weight in bulk packaging: 19 kg
- Height of the standard (outer) box: 402 mm
- Main (outer) case length: 320 mm
- Data transfer
- Routing/Switching Throughput: 12.5 Gbps
- Address table size: 2048 entries
- Forwarding speed: 8.929 Mpps
- Jumbo Frame Compatible: Yes
- Jumbo Frames Expansion: 9216
- Store-and-forward: Yes
- Packet buffer memory: 0.125 MB
- Power over Ethernet (PoE)
- Power over Ethernet (PoE) power per port: 30 W
- Number of Fast Ethernet (PoE) ports: 3
- Total Power over Ethernet (PoE) budget: 120 W
- PoE Support: Yes
- Power over Ethernet Plus (PoE +) number of ports: 1
- Fiber optic
- Optical Module Switch Type: Gigabit Ethernet
| Name | Details |
|---|---|
| Category | Computers and accessories |
| Producer | CUDY |
| Colour | Black |
