Cudy GS2018PS2 Managed L2 Gigabit Ethernet (10/100/1000) PoE Support 1U Black
Cudy GS2018PS2 Managed L2 Gigabit Ethernet (10/100/1000) PoE Support 1U Black
Cudy GS2018PS2 Managed L2 Gigabit Ethernet (10/100/1000) PoE Support 1U Black
PRICE:
345,99
€
IN A WAREHOUSE
3 pcs
We'll ship this product in 4 days.
FREE EUROPE SHIPPING FROM 149 €!
30 DAYS FOR A RETURN!
Sign up and unlock up to 10% off!
- Design
- Product color: Black
- LED diodes
- Action
- PoE
- Link
- Power supply
- System
- Reset button: Yes
- Rack mounting options: Yes
- Layout: 1U
- Power
- AC input frequency: 50/60 Hz
- AC input voltage: 100 - 240 V
- Protection against sudden voltage increases
- Yes
- 15 kV
- Power source: AC
- Security
- Encryption/Security
- SSH
- HTTPS
- SSH-2
- IGMP snooping: Yes
- Queue Planning Algorithms: PQ + WRR
- MAC address entries
- Dynamic MAC address entries
- Static MAC address entries
- Password protection: Yes
- BPDU Filtering/Protection: Yes
- Packet Filtering: Y
- IP-MAC-Port Binding: Yes
- Authentication type: IEEE 802.1x, RADIUS
- Encryption/Security
- Management features
- Website management: Yes
- Configuring Location Settings (CLI): Yes
- Quality of Service (QoS) Support: Yes
- Switch type: Managed
- System Event Report: Yes
- Switch Layer: L2
- Working conditions
- Permissible operating altitude (above sea level): 0 - 3048 m
- Permissible relative humidity: 5 - 90%
- Permissible altitude (above sea level): 0 - 3048 m
- Relative humidity range: 10 - 90%
- Temperature range (operation): -20 - 50 °C
- Temperature range (storage): -40 - 85 °C
- Network
- Communication standards
- IEEE 802.3at
- IEEE 802.3z
- IEEE 802.1x
- IEEE 802.1p
- IEEE 802.3u
- IEEE 802.1w
- IEEE 802.3ad
- IEEE 802.3af
- IEEE 802.3x
- IEEE 802.3i
- IEEE 802.1Q
- IEEE 802.3
- IEEE 802.3ab
- IEEE 802.1s
- IEEE 802.1D
- IEEE 802.1ab
- Frequency Limit: Yes
- Spanning Tree Protocol: Yes
- Virtual LAN Features
- MAC address-based VLAN
- Voice VLAN
- Port-based VLAN
- Supported cable types
- Cat4
- Cat5
- Cat6
- Cat3
- Cat5e
- Copper Ethernet cabling technology
- 10BASE-T
- 1000BASE-T
- 100BASE-TX
- 10G Support: No
- VLAN support: Yes
- Port Mirroring: Yes
- MAC address auto-learning supported: Yes
- Ethernet Ring Protection Switching (ERPS): Yes
- MAC address auto-aging supported: Yes
- Flow Control Support: Yes
- Connection Aggregator: Yes
- Quick lower: Yes
- Number of VLANs: 4096
- Communication standards
- Efficiency
- Flash memory size: 16 MB
- MTBF (Mean Time Between Failures): 50000 h
- Internal memory capacity: 128 MB
- Protocols
- Management protocols: HTTP, HTTPS, Telnet, SSH V1/V2, SNMP V1/V2/V3, RMON V2
- GARP VLAN Registration Protocol (GVRP): Yes
- Ports and interfaces
- Console port: RJ-45
- Number of Gigabit Ethernet ports: 16
- Number of connection ports: 2
- Basic RJ-45 Switching Number of Ethernet Ports: 16
- Basic Ethernet switching RJ-45 ports type: Gigabit Ethernet (10/100/1000)
- Number of SFP Module slots: 2
- Data transfer
- Routing/switching capacity: 40 Gbit/s
- Jumbo Frame Compatible: Yes
- Packet buffer memory: 4 MB
- Number of rounds: 8
- Address table size: 8000 entries
- Jumbo Frames Expansion: 9600
- Transfer speed: 19.76 Mpps
- Power over Ethernet (PoE)
- Power over Ethernet (PoE) power per port: 30 W
- Number of Fast Ethernet (PoE) ports: 16
- PoE Support: Yes
- Total Power over Ethernet (PoE) budget: 200 W
- Multicast functions
- Multicast features: Multicast traffic suppression
- Multicast Support: Yes
- Multicast Listener Discovery (MLD) snooping: v1/v2
- Fiber optic
- Fiber Ethernet cabling technology: 1000Base-X
| Name | Details |
|---|---|
| Producer | CUDY |
