CyberPower VP700ELCD UPS line-interactive technology 0.7 kVA 390 W 4 x mains sockets
CyberPower VP700ELCD UPS line-interactive technology 0.7 kVA 390 W 4 x mains sockets
Sign up and unlock up to 10% off!
- Characteristics
- Actual power: 390 W
- Audible alarm: Yes
- Power Protection Features: Over Voltage Protection
- Response time (typical): 4 ms
- Noise level: 40 dB
- EMI/RFI Filter: Yes
- Maximum configurable power: 0.7 kVA
- Overvoltage protection: Yes
- Input frequency: 50/60 Hz
- Maximum current: 3.04 A
- Output frequency: 50/60 Hz
- Waveform: Sine
- Output voltage regulation: 10%
- Number of input phases: 1
- Output operating voltage (minimum): 230 V
- Impact Energy Rating: 450 J
- Automatic Voltage Regulation (AVR): Yes
- Input operating voltage (minimum): 167 V
- UPS topology: Line-interactive technology
- Audible alarm modes: Battery alarm, Fault, Low battery alarm, Overload alarm
- Heat emission: 9.5 BTU/h
- Number of output phases: 1
- Input operating voltage (maximum): 295 V
- Design
- Product color: Black
- LEDs: Yes
- Display type: LCD
- Layout: Tower
- Cable length: 1.5 m
- Housing material: Plastic
- Weight and dimensions
- Product depth: 260 mm
- Product width: 100 mm
- Product weight: 5.14 kg
- Product height: 227 mm
- Working conditions
- Temperature range (storage): -20 - 50 °C
- Relative humidity range: 0 - 90%
- Permissible relative humidity: 0 - 90%
- Temperature range (operation): 0 - 40 °C
- Permissible operating altitude (above sea level): 0 - 3000 m
- Permissible altitude (above sea level): 0 - 3000 m
- Packaging data
- Package width: 300 mm
- Package height: 335 mm
- Package depth: 143 mm
- Weight with packaging: 5.76 kg
- Package contents
- Cables: USB cable
- User Manual: Yes
- Certificates
- Certificates of conformity: RoHS
- Ports and interfaces
- USB port: Yes
- Number of USB 2.0 ports: 1
- Cabling technology: 10/100/1000Base-T(X)
- Serial communication ports: 1
- Number of Ethernet LAN ports (RJ-45): 2
- Number of network sockets: 4 x network socket
- RS-232 port: 1
- Plug: C14 panel
- Serial interface: Yes
- USB port type: USB Type B
- AC Output Types: Type F
- SCSI interface: RS-232
- Battery
- Typical backup time at full load: 1 min
- Typical backup time at half load: 10 min
- Battery type: Lead acid (VRLA)
- Charging time: 8 h
- Logistics data
- Country of origin: China
- Harmonized System (HS) code: 8504408590
- Sustainable development
- Sustainability: Yes
| Name | Details |
|---|---|
| Producer | CyberPower |
