D-Link DGS-1100-05PDV2 Network Links Managed Gigabit Ethernet (10/100/1000) PoE Support Black
D-Link DGS-1100-05PDV2 Network Links Managed Gigabit Ethernet (10/100/1000) PoE Support Black
D-Link DGS-1100-05PDV2 Network Links Managed Gigabit Ethernet (10/100/1000) PoE Support Black
PRICE:
140,99
€
IN A WAREHOUSE
9 pcs
We'll ship this product in 8 days.
FREE EUROPE SHIPPING FROM 149 €!
30 DAYS FOR A RETURN!
Sign up and unlock up to 10% off!
- Design
- Product color: Black
- Rack mounting options: No
- Power
- Power source: PoE
- Power Supply Included: No
- Power consumption: 3.24 W
- Power consumption (max): 24.08 W
- Weight and dimensions
- Product width: 150 mm
- Product weight: 380 g
- Product height: 28 mm
- Product depth: 97 mm
- Security
- Supports SSH/SSL: Yes
- IGMP snooping: Yes
- Queue Planning Algorithms: Weighted Round Robin (WRR)
- DHCP functions: DHCP client
- IGMP entries: 128
- Static Port Protection: Yes
- MAC Address Entries: Static MAC Address Entries
- Management features
- Website management: Yes
- Quality of Service (QoS) Support: Yes
- Switch type: Managed
- Working conditions
- Temperature range (operation): 0 - 40 °C
- Permissible relative humidity: 0 - 95%
- Temperature range (storage): -40 - 70 °C
- Relative humidity range: 0 - 90%
- Network
- Communication standards
- IEEE 802.3af
- IEEE 802.3x
- IEEE 802.3ab
- IEEE 802.3az
- IEEE 802.3at
- IEEE 802.3u
- IEEE 802.3
- Data transfer speed via Ethernet LAN: 10000 Mbit/s
- Auto-Negotiation: Yes
- 10G Support: No
- Auto MDI/MDI-X: Yes
- Full duplex: Yes
- Traffic Growth Control: Yes
- Virtual LAN Features
- Tagged VLAN
- Management VLAN
- Port-based VLAN
- Voice VLAN
- Flow Control Support: Yes
- VLAN support: Yes
- Head-of-line (HOL) blocking: Yes
- Port Mirroring: Yes
- Number of VLANs: 4094
- Half-duplex: Yes
- Communication standards
- Efficiency
- Noise level: 0 dB
- MTBF (Mean Time Between Failures): 2357475 h
- Flash memory size: 2 MB
- No fan: Yes
- Certificates
- Certificates of conformity
- CB
- BSMI
- Low Voltage Directive (LVD)
- Federal Communications Commission (FCC)
- VCCI
- Certificates of conformity
- Ports and interfaces
- Basic RJ-45 Switching Number of Ethernet Ports: 5
- Number of Gigabit Ethernet ports: 5
- Basic Ethernet switching RJ-45 ports type: Gigabit Ethernet (10/100/1000)
- Logistics data
- Harmonized System (HS) code: 85176990
- Data transfer
- Jumbo Frames Expansion: 9216
- Number of rounds: 4
- Transfer speed: 7.44 Mpps
- Address table size: 2000 entries
- Number of lines: 1
- Routing/switching capacity: 10 Gbit/s
- Packet buffer memory: 1 MB
- Power over Ethernet (PoE)
- Number of Fast Ethernet (PoE) ports: 2
- Power over Ethernet (PoE) power per port: 18 W
- PoE Support: Yes
| Name | Details |
|---|---|
| Producer | D-Link |
