D-link-DGS-1510-28XMP/E 28-Port Stackable switch
D-link-DGS-1510-28XMP/E 28-Port Stackable switch
D-link-DGS-1510-28XMP/E 28-Port Stackable switch
PRICE:
1797,99
€
IN A WAREHOUSE
4 pcs
We'll ship this product in 8 days.
FREE EUROPE SHIPPING FROM 149 €!
30 DAYS FOR A RETURN!
Sign up and unlock up to 10% off!
- Technical details
- Gross pallet width: 120 cm
- Gross pallet length: 110 cm
- Pallet height (sea): 2.08 m
- Gross pallet weight (sea): 561.6 kg
- Products per shipping crate (inner): 3 pcs.
- Pallet height (air): 2.08 m
- Collecting boxes (external) per pallet (air): 24 pcs.
- Shipping box length: 53 cm
- Gross shipping box (inner) weight: 22.6 kg
- Gross pallet weight (air): 561.6 kg
- Products per pallet (sea): 72 pcs.
- Delivery box width: 38.5 cm
- Quantity per pallet (air): 72 pcs.
- Net weight of the delivery box: 14.3 kg
- Delivery box height: 48.5 cm
- Collective (external) boxes per pallet (sea): 24 pcs.
- Design
- Rack mounting options: Yes
- Number of fans: 2 fans
- Safety: cUL, CB
- Stackable: Yes
- LED diodes
- Link
- PoE
- Action
- Speed
- Power supply
- Product color
- Gray
- Black
- Power
- Power consumption (max): 436.3 W
- Power source: AC
- Power supply included: Yes
- AC input voltage: 100 - 240 V
- Weight and dimensions
- Product width: 440 mm
- Product height: 44 mm
- Product depth: 308.5 mm
- Product weight: 4.25 kg
- Security
- IGMP snooping: Yes
- DHCP functions
- DHCP server
- DHCP client
- Access Control List (ACL) Rules: 768
- BPDU Filtering/Protection: Yes
- Authentication: MAC-based authentication, Port-based authentication
- Access Control List (ACL): Yes
- Supports SSH/SSL: Yes
- Encryption/Security
- SSH-2
- SNMP
- SSL/TLS
- 802.1x RADIUS
- SSH
- EAP
- Management features
- Quality of Service (QoS) Support: Yes
- Traffic Classification: Yes
- Switch type: Managed
- Switch Layer: L2/L3
- System Event Report: Yes
- Working conditions
- Permissible relative humidity: 0 - 95%
- Relative humidity range: 0 - 95%
- Heat emission: 1487.78 BTU/h
- Temperature range (storage): -20 - 70 °C
- Temperature range (operation): -5 - 50 °C
- Network
- Copper Ethernet cabling technology
- 100BASE-TX
- 10BASE-T
- 1000BASE-T
- Auto MDI/MDI-X: Yes
- Full duplex: Yes
- 10G Support: Yes
- VLAN support: Yes
- Number of VLANs: 4094
- Flow Control Support: Yes
- Connection Aggregator: Yes
- Spanning Tree Protocol: Yes
- Virtual LAN Features
- Tagged VLAN
- Protocol-based VLAN
- Supported cable types
- Cat5
- Cat5e
- Head-of-line (HOL) blocking: Yes
- Port Mirroring: Yes
- MAC address auto-learning supported: Yes
- Traffic Growth Control: Yes
- Auto-Negotiation: Yes
- Communication standards
- IEEE 802.3
- IEEE 802.3af
- IEEE 802.3x
- IEEE 802.3at
- IEEE 802.1D
- IEEE 802.1Q
- IEEE 802.1p
- IEEE 802.3ae
- IEEE 802.1w
- IEEE 802.1s
- IEEE 802.3ab
- IEEE 802.1x
- IEEE 802.3ad
- Copper Ethernet cabling technology
- Efficiency
- Internal memory capacity: 256 MB
- Built-in processor: Yes
- MTBF (Mean Time Between Failures): 274796 h
- Flash memory size: 32 MB
- Processor clock speed: 400 MHz
- Packaging data
- Package depth: 510 mm
- Package height: 121 mm
- Package width: 450 mm
- Weight with packaging: 7.06 kg
- Ports and interfaces
- Basic Ethernet switching RJ-45 ports type: Gigabit Ethernet (10/100/1000)
- Basic RJ-45 Switching Number of Ethernet Ports: 24
- Fiber optic connector: SFP+
- Number of SFP+ Module slots: 4
- Logistics data
- Harmonized System (HS) code: 85176990
- Data transfer
- Routing/switching capacity: 128 Gbit/s
- Jumbo Frame Compatible: Yes
- Packet buffer memory: 1.5 MB
- Address table size: 16384 entries
- Throughput: 95.24 Mpps
- Store-and-forward: Yes
- Number of rounds: 8
- Jumbo Frames Expansion: 9216
- Power over Ethernet (PoE)
- Number of Fast Ethernet (PoE) ports: 24
- Power over Ethernet (PoE) power per port: 30 W
- Total Power over Ethernet (PoE) budget: 370 W
- PoE Support: Yes
- Multicast functions
- Multicast Support: Yes
| Name | Details |
|---|---|
| Producer | D-Link |
