Dahua IPC-HDW3849QM-S-IL-0280B-Black IP camera
Dahua IPC-HDW3849QM-S-IL-0280B-Black IP camera
Sign up and unlock up to 10% off!
- Design
- Product color: White
- Security features: Dust resistant
- IP protection class: IP67
- Mounting type: Ceiling / Wall / Pole
- Layout: Dome
- Power
- DC Output (Volts): 12
- Power consumption: 2.6 W
- Power supply type: DC, PoC
- Weight and dimensions
- Diameter: 12.2 cm
- Product width: 99.1 mm
- Product weight: 480 g
- Security
- Active intrusion alarm: Yes
- Video motion detection: Yes
- Intelligent Video Surveillance (IVS) Features
- A tripod
- Intrusion
- Management features
- Web browser: Yes
- Management software: Smart PSS; DSS; DMSS
- Working conditions
- Temperature range (storage): -40 - 60 °C
- Temperature range (operation): -40 - 55 °C
- Relative humidity range: 0 - 95%
- Network
- Ethernet interface type: Fast Ethernet
- Quality of Service (QoS) Support: Yes
- Wired LAN: Yes
- Streaming method: Multicast
- Number of users: 20 users
- System requirements
- Support for mobile operating systems
- Android
- iOS
- Support for mobile operating systems
- Efficiency
- Wide Dynamic Range (WDR): Yes
- Infrared (IR) Cut-off Filter: Yes
- Model: IP Security Camera
- Connection method: Wired
- Day/Night Mode: Yes
- Intended use: Outdoor
- Built-in light: Yes
- Packaging data
- Weight with packaging: 620 g
- Package contents
- Number of cameras: 1
- Audio
- Supported audio formats
- PCM
- G.711 A-law
- G.726
- G.711 μ-law
- Signal-to-noise ratio: 56 dB
- Supported audio formats
- Data carrier
- Internal memory capacity: 256 MB
- ROM capacity: 128 MB
- Ports and interfaces
- Number of Ethernet LAN ports (RJ-45): 1
- Camera
- Rotation angle: 360°
- White balance
- Street lamp
- Region
- Natural
- Manual
- External
- Automatic
- Swivel range: 0 - 360°
- Camera shutter type: Electronic
- Shutter speed: 1/3 –1/100000
- Tilt angle range: 0 - 78°
- Photosensitive matrix
- Image sensor type: CMOS
- Number of sensors: 1
- CCD sensor size: 25.4 / 2.7 mm (1 / 2.7")
- Progressive Scan: Yes
- Night mode
- Night Vision Distance: 30 m
- LED type: Infrared
- Night mode: Yes
- Video
- Image rotation and mirroring: Yes
- Backlight compensation: Yes
- Video transmission: Yes
- Regional Area of Interest (ROI) Coding: Yes
- Supported graphics resolutions
- 704 x 480
- 2688 x 1520
- 352 x 240
- 704 x 576
- 2048 x 1536 (QXGA)
- 640 x 480 (VGA)
- 3840 x 2160
- 1920 x 1080 (HD 1080)
- 3072 x 2048
- 1280 x 720 (HD 720)
- 3072 x 1728
- 2304 x 1296
- 1280 x 960
- 352 x 288
- 2880 x 1620
- Compression formats
- M-JPEG
- H.265
- H.264
- H.264+
- H.264H
- H.265+
- H.264B
- Control Gain: Auto/Manual
- Total megapixels: 8 MP
- Highlight Compensation (HLC): Yes
- Maximum resolution: 3840 x 2160 px
- Privacy Mask: Yes
- Data rate control: Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
- Lens system
- Number of lenses: 2.8
- Minimum aperture: 1.6
| Name | Details |
|---|---|
| Producer | DAHUA |
