DELL PowerEdge R470 server 960 GB Rack (1U) Intel Xeon 6 6517P 3.2 GHz 32 GB DDR5-SDRAM 1100 W
DELL PowerEdge R470 server 960 GB Rack (1U) Intel Xeon 6 6517P 3.2 GHz 32 GB DDR5-SDRAM 1100 W
Sign up and unlock up to 10% off!
- Processor
- Number of threads: 32
- Number of processor cores: 16
- Processor manufacturer: Intel
- System bus rate: 24 GT/s
- Maximum processor clock speed: 4.2 GHz
- Processor type: Intel Xeon 6
- Memory types supported by the processor: DDR5-SDRAM
- Processor clock speed: 3.2 GHz
- Memory clock speed supported by the processor: 6400 MHz
- Processor Cache: 72 MB
- Number of processors: 1
- Thermal Design Power (TDP): 190 W
- Processor model: 6517P
- Memory
- Memory slots: DIMM x 16
- RAM: 32 GB
- RAM type: DDR5-SDRAM
- Buffer memory type: Registered (buffered)
- Memory chip: 1 x 32 GB
- Memory Ranking: 2
- Memory data transfer rate: 6400 MT/s
- Design
- Product color: Black
- Housing: Rack (1U)
- Frame: Yes
- Power
- Power supply: 1100 W
- Backup Power Supply (RPS) Support: Yes
- Number of installed redundant power sources: 2
- Power supply input voltage: 100 - 240 V
- Weight and dimensions
- Product width: 482 mm
- Product height: 42.8 mm
- Efficiency
- Remote administration: iDRAC10, Enterprise 17G
- Expansion slots
- PCI Express x16 (Gen 5.x) slots: 2
- Software
- Installed operating system: None
- Certificates
- 80 PLUS Certified: 80 PLUS Titanium
- Data carrier
- Supported SSD sizes: 2.5"
- SSD size: 2.5"
- RAID Service: Yes
- Hot Plug Support: Yes
- Supported RAID Controllers: PERC H965i Controller, Front, DC-MHS
- Optical drive: No
- Total disk capacity: 960 GB
- Number of SSDs supported: 8
- SSD storage interface: SATA III
- SSD memory capacity: 480 GB
- Number of SSDs installed: 2
- Ports and interfaces
- Number of VGA (D-Sub) ports: 1
- Number of USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports: 2
- Number of Ethernet LAN ports (RJ-45): 1
- Other functions
- Bits per sector: 512
- Data transfer speed: 6 Gbit/s
- Target Workload: Read Intensive (RI)
- Open Compute Project (OCP): 1x16 Onboard
- Carbon footprint
- Carbon dioxide emissions, production (kg CO2e): 553.13
- Total carbon dioxide emissions, standard deviation (kg CO2e): 1827
- End-of-life carbon dioxide emissions (kg CO2e): 22.94
- Carbon dioxide emissions, energy consumption (kg CO2e): 1799.59
- PAIA Version: PAIA 1.4.2, 2025
- Total carbon footprint (kg of CO2e): 2549
- Carbon dioxide emissions, logistics (kg CO2e): 170.78
| Name | Details |
|---|---|
| Category | Computers and accessories |
| Producer | Dell |
| Department | Electronics |
