FSP MEGA TI 1650W 20+4 pin ATX power supply module Black
FSP MEGA TI 1650W 20+4 pin ATX power supply module Black
FSP MEGA TI 1650W 20+4 pin ATX power supply module Black
PRICE:
560,99
€
IN A WAREHOUSE
6 pcs
We'll ship this product in 10 days.
FREE EUROPE SHIPPING FROM 149 €!
30 DAYS FOR A RETURN!
Sign up and unlock up to 10% off!
- Design
- Number of fans: 1 fan
- Cooling type: Active
- Fan bowl diameter: 13.5 cm
- Built-in switch: Yes
- Product color: Black
- Power
- AC input voltage: 110 - 240 V
- Maximum output current (+3.3V): 20 A
- Power protection features
- Low voltage protection
- Short circuit
- Overheating protection
- Protection against overvoltage
- Overcurrent
- Overload protection
- No load operation
- Surge & inrush protection (SIP)
- PFC (Power Factor Correction) Type: Active
- Efficiency: 94%
- Maximum output current (+12V): 137.5 A
- Power factor: 0.9
- Total power (+3.3V): 120 W
- Total power (+5 Vsb): 20 W
- Total power (+5V): 120 W
- AC input frequency: 50/60 Hz
- Maximum output current (+5V): 20A
- Total power: 1650 W
- Input current: 10 - 15 A
- Total power (-12V): 3.6 W
- Maximum output current (+5 Vsb): 4 A
- Maximum output current (-12V): 0.3A
- Weight and dimensions
- Product height: 86 mm
- Product width: 150 mm
- Product depth: 180 mm
- Working conditions
- Temperature range (operation): 0 - 50 °C
- Efficiency
- Cybenetics Certification: Titanium
- Cybenetics noise rating: A++
- 80 PLUS Certified: 80 PLUS Titanium
- Power supply type (PSU): ATX
- Intended use: PC
- ATX version: 3.1
- Bearing Technology: FDB
- Ports and interfaces
- Number of SATA power connectors: 10
- CPU power supply connector (4+4 pin): Yes
- PCI Express power cable length: 70 cm
- Peripheral (Molex) Power Cable Length
- 500 mm
- 155
- PCI Express slot: Yes
- Motherboard power connector: 20+4 pin ATX
- PCI Express power connectors (12-pin): 1
- Number of SATA power cables: 3
- Peripheral (Molex) Power Connectors (4-pin): 6
- PCI Express power connectors (6+2 pin): 6
- Wiring Type: Fully Modular
- Motherboard cable length: 60 cm
- SATA power cable length
- 500 mm
- 155
- CPU power cable length: 70 cm
- Logistics data
- Warranty period: 10 years
| Name | Details |
|---|---|
| Producer | Fortron |
