GIGABYTE TRX50 AI TOP-2B Motherboard AMD TRX50 Socket sTR5 Extended ATX
GIGABYTE TRX50 AI TOP-2B Motherboard AMD TRX50 Socket sTR5 Extended ATX
GIGABYTE TRX50 AI TOP-2B Motherboard AMD TRX50 Socket sTR5 Extended ATX
PRICE:
1562,99
€
IN A WAREHOUSE
2 pcs
We'll ship this product in 8 days.
FREE EUROPE SHIPPING FROM 149 €!
30 DAYS FOR A RETURN!
Sign up and unlock up to 10% off!
- Technical details
- Warranty period: 3 years
- Processor
- Supported CPU sockets: Socket sTR5
- Processor manufacturer: AMD
- Processor
- AMD Ryzen Threadripper PRO 7000 WX-Series
- AMD Ryzen Threadripper 7000 Series
- Processor socket: Socket sTR5
- Graphics
- DirectX Version: 12.0
- Parallel Processing Support: Not Supported
- HDCP: No
- Memory
- Maximum memory capacity: 2 TB
- Unbuffered memory: No
- Supported memory types: DDR5-SDRAM
- Supported memory clock speed (max): 5200 MHz
- Number of memory slots: 8
- ECC Compatibility: ECC
- Memory slot type: DIMM
- Memory Channel Support: Quad Channel
- Characteristics
- Motherboard Layout: AMD TRX50
- Audio chip: Realtek ALC897 / Realtek ALC4080
- Audio output channels: 2.0 ch.
- Product color: Black
- Monitoring computer status
- Fan
- Water cooling
- Tension
- Temperature
- Chipset Board Family: AMD
- Supported Windows operating systems: Windows 11 x64
- Power supply type: ATX
- Intended use: PC
- Motherboard format: Extended ATX
- Cooling type: Active
- Supported Linux operating systems: Ubuntu 24.04 LTS
- Weight and dimensions
- Product depth: 330 mm
- Product width: 305 mm
- Product height: 35 mm
- Internal I/O
- TPM Connector: Yes
- Number of case fan connectors: 6
- CPU fan connector: Yes
- EPS power supply connector (8-pin): Yes
- ATX power socket (24-pin): Yes
- USB 3.2 Gen 1 (3.1 Gen 1) ports: 2
- Front panel connector: Yes
- Number of SATA III connectors: 4
- Number of USB 2.0 ports: 2
- Front panel audio connector: Yes
- RGB LED: Yes
- 12V power connector: Yes
- Number of CPU fan connectors: 2
- Number of water pump connections: 5
- Number of EPS power connectors (8-pin): 2
- Number of temperature sensor headers: 2
- USB 3.2 Gen 2x2 ports: 1
- Number of RGB LED connectors: 4
- Number of noise detection headers: 1
- Network
- LAN controller: Marvell AQtion AQC113C
- Bluetooth: Yes
- Basic Wi-Fi standard: Wi-Fi 7 (802.11be)
- Wi-Fi: Yes
- Ethernet network interface type
- 2.5 Gigabit Ethernet
- 5 Gigabit Ethernet
- Fast Ethernet
- 10 Gigabit Ethernet
- Gigabit Ethernet
- Wired LAN: Yes
- Wi-Fi standards
- Wi-Fi 6E (802.11ax)
- Wi-Fi 6 (802.11ax)
- Wi-Fi 7 (802.11be)
- 802.11g
- 802.11a
- Wi-Fi 4 (802.11n)
- Wi-Fi 5 (802.11ac)
- 802.11b
- Bluetooth version: 5.3
- WLAN controller model: Qualcomm QCNCM865
- BIOS
- BIOS Type: UEFI AMI
- Clear CMOS Button: Yes
- ACPI version: 5.0
- BIOS memory size: 256 Mbit
- System BIOS (SMBIOS) version: 2.7
- Clear CMOS Jumper: Yes
- Desktop Management Interface (DMI) Version: 2.7
- Packaging data
- Package depth: 397 mm
- Weight with packaging: 6.47 kg
- Package width: 379 mm
- Package height: 105 mm
- Package contents
- Batteries included: Yes
- Antenna Included: Yes
- Screws Included: Yes
- Memory drivers
- Supported hard drive interfaces: M.2, PCI Express 5.0, SATA III
- Supported drive types: HDD & SSD
- RAID levels
- 1
- 0
- 10
- RAID Service: Yes
- Number of supported storage drive sizes: 8
- Number of supported HDDs: 4
- Rear Panel I/O Ports
- DisplayPort Quantity: 1
- Number of Ethernet LAN ports (RJ-45): 2
- Number of USB4 Gen 3x2 ports: 2
- Headphone outputs: 1
- WiFi-AP Antenna Jack Plug: 2
- Number of USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports: 6
- Line Input: Yes
- Expansion slots
- Number of M.2 (M) slots: 4
- PCI Express x16 (Gen 5.x) slots: 4
- 3. largest M.2 key size: 2280
- 1. largest M.2 key size: 2280
- 3. M.2 highest generation PCI Express: 5.0
- 4. M.2 highest generation PCI Express: 5.0
- 2. M.2 highest generation PCI Express: 5.0
- 2nd largest M.2 key size: 2280
- 4. largest M.2 key size: 2280
- 1. M.2 highest generation PCI Express: 5.0
- Battery
- Number of battery compartments: 1
- Battery weight: 3 g
- Lithium battery weight: 0.07 g
- Battery type: Lithium-Manganese Dioxide (LiMnO2)
- Supported battery type: CR2032
- Logistics data
- Country of origin: China
- Products per shipping crate (inner): 1 pc.
| Name | Details |
|---|---|
| Producer | Gigabyte |
