HDMI 4K30Hz Extender 70m over Twisted Pair HDBaseT HDCP2.2 IR RS232 PoC (Power over Cable) Set
HDMI 4K30Hz Extender 70m over Twisted Pair HDBaseT HDCP2.2 IR RS232 PoC (Power over Cable) Set
HDMI 4K30Hz Extender 70m over Twisted Pair HDBaseT HDCP2.2 IR RS232 PoC (Power over Cable) Set
PRICE:
241,99
€
IN A WAREHOUSE
above 10 pcs
We'll ship this product in 9 days.
FREE EUROPE SHIPPING FROM 149 €!
30 DAYS FOR A RETURN!
Sign up and unlock up to 10% off!
- Technical details
- Country of origin: China
- Packaging capacity: 2332.75 cm³
- Characteristics
- Product color: Black
- Bandwidth: 10.2 Gbps
- Two-way support: Yes
- Supported cable types
- Cat8
- Cat6
- Cat7
- Cat5e
- Supported video modes
- 1080p
- 1080i
- 2160i
- 2160p
- Maximum transfer distance: 70 m
- Wall mountable: Yes
- HDCP version: 1.4/2.2
- Materials: Metal
- Electrostatic discharge (ESD) protection: Yes
- Maximum resolution: 3840 x 2160 px
- LEDs: Yes
- Maximum refresh rate: 30 Hz
- Model: AV Transmitter and Receiver
- HDCP: Yes
- Power
- PoE Support: No
- Power consumption (receiver) (max): 20 W
- Power consumption (transmitter) (max): 20 W
- Operating voltage (supplied): 24 V
- Operating voltage (received): 24 V
- External Power Adapter: Yes
- Weight and dimensions
- Transmitter weight: 200 g
- Receiver dimensions (W x D x H): 115 x 65 x 17 mm
- Transmitter dimensions (WxDxH): 115 x 65 x 17 mm
- Receiver weight: 200 g
- Working conditions
- Temperature range (operation): 0 - 40 °C
- Packaging data
- Number of pieces: 2
- Package depth: 155 mm
- Weight with packaging: 825 g
- Package width: 215 mm
- Package height: 70 mm
- Package contents
- Mounting Brackets Included: Yes
- Wires: Infrared
- AC adapter: Yes
- User Manual: Yes
- Ports and interfaces
- Connection method: Wired
- Serial communication ports: 2
- HDMI in: 1
- Remote IR Outputs: 2
- SCSI interface: RS-232
- RJ-45 inputs: 1
- DC output socket: Yes
- Number of HDMI outputs: 1
- IR Remote Input: 2
- RJ-45 outputs: 1
- Logistics data
- Mask with serial number: 85176200
| Name | Details |
|---|---|
| Category | Computers and accessories |
| Producer | DIGITUS |
| Department | Electronics |
