Hewlett Packard Enterprise Aruba AP-565 Access Point
Hewlett Packard Enterprise Aruba AP-565 Access Point
Sign up and unlock up to 10% off!
- Characteristics
- Bluetooth version: 5.0
- Frequency band: 20/40 (2.4GHz), 20/40/80 (5GHz), peak data rate 1.49 Gbps, maximum data rate 1.78 Gbps
- Maximum data transfer rate (2.4 GHz): 574 Mbit/s
- Image expansion method
- OFDMA
- DSSS
- OFDM
- Maximum data transfer rate: 1774 Mbit/s
- Maximum data transfer rate (5 GHz): 1200 Mbit/s
- ALTHOUGH: Yes
- MIMO Type: Multi User MIMO
- Modulation
- QPSK
- 1024-QAM
- CCK
- 64-QAM
- 16-QAM
- 256-QAM
- BPSK
- 2.4GHz: Yes
- Data transfer speed via Ethernet LAN: 1000 Mbit/s
- 5GHz: Yes
- Bluetooth: Yes
- Communication standards
- IEEE 802.11mc
- IEEE 802.11ax
- Auto MDI/DMI-X Switching: Yes
- Design
- Intended use: Rod, Wall
- Product color: White
- Application: External
- Power
- Power consumption (max): 15.6 W
- PoE Support: Yes
- Weight and dimensions
- Product height: 165 mm
- Product depth: 130 mm
- Product weight: 1.03 kg
- Product width: 165 mm
- Security
- Encryption/Security
- WPA3
- WPA2
- Encryption/Security
- Working conditions
- Temperature range (storage): -40 - 70 °C
- Relative humidity range: 5 - 95%
- Permissible operating altitude (above sea level): 0 - 3000 m
- Temperature range (operation): -40 - 55 °C
- Certificates
- Certificates of conformity
- Electromagnetic compatibility (EMC)
- CE
- ISED
- Federal Communications Commission (FCC)
- Low Voltage Directive (LVD)
- Certificates of conformity
- Ports and interfaces
- Number of Ethernet LAN ports (RJ-45): 1
- Supported USB type: USB Type-C
- Antenna
- Antenna Features: Integrated Antenna
- Antenna gain level (max): 5.4 dBi
- Antenna Direction Type: Omnidirectional Antenna
- Antenna type: Internal
- Other functions
- Weight (imperial): 1.03 kg (2.27 lbs)
- Logistics data
- Harmonized System (HS) code: 85176990
