Frequency range: 864 MHz (Long Range), 868.4 MHz (Mesh)
Overheating protection: Yes
LEDs: Yes
Product Type: Smart Relay
Maximum indoor range: 80 m
Housing material: Plastic
DIN rail mounting: Yes
Cable cross-section: 0.5 - 2.5 mm²
Overcurrent protection: Yes
Remote controlled: Yes
Connectivity: Z-Wave
Security: AES-128
Power
AC input frequency: 50/60 Hz
Power consumption: 0.3 W
AC input voltage: 110 - 240 V
Maximum switching current (AC): 16 A
Maximum switching voltage (AC): 240 V
Weight and dimensions
Product weight: 75 g
Product height: 94 mm
Product width: 19 mm
Product length: 69 mm
Working conditions
Temperature range (operation): -20 - 40 °C
Relative humidity range: 30 - 70%
Name
Details
Producer
Shelly
