Intellinet 561198 Network Links Managed L2+ Gigabit Ethernet (10/100/1000) PoE Support 1U Black
Intellinet 561198 Network Links Managed L2+ Gigabit Ethernet (10/100/1000) PoE Support 1U Black
Intellinet 561198 Network Links Managed L2+ Gigabit Ethernet (10/100/1000) PoE Support 1U Black
PRICE:
585,99
€
IN A WAREHOUSE
LAST ITEM!
We'll ship this product in 8 days.
FREE EUROPE SHIPPING FROM 149 €!
30 DAYS FOR A RETURN!
Sign up and unlock up to 10% off!
- Design
- Product color: Black
- Layout: 1U
- Rack mounting options: Yes
- Housing material: Metal
- Number of fans: 2 fans
- LED diodes
- Link
- Power supply
- Action
- PoE
- Power
- Power consumption (max): 410 W
- AC input voltage: 100 - 240 V
- AC input frequency: 50 - 60 Hz
- Weight and dimensions
- Product weight: 2.5 kg
- Product depth: 208 mm
- Product height: 44 mm
- Product width: 440 mm
- Security
- Encryption/Security
- SNMPv3
- SSH-2
- SNMP
- ICMP Attack Prevention: Yes
- Encryption/Security
- Management features
- Switch Layer: L2+
- Switch type: Managed
- Quality of Service (QoS) Support: Yes
- Website management: Yes
- Working conditions
- Relative humidity range: 10 - 90%
- Temperature range (operation): 0 - 40 °C
- Temperature range (storage): -20 - 90 °C
- Network
- Traffic Growth Control: Yes
- Auto MDI/MDI-X: Yes
- Frequency Limit: Yes
- Full duplex: Yes
- Connection Aggregator: Yes
- Flow Control Support: Yes
- Auto-Negotiation: Yes
- Communication standards
- IEEE 802.1D
- IEEE 802.1Q
- IEEE 802.3
- IEEE 802.3af
- IEEE 802.3x
- IEEE 802.3ad
- IEEE 802.3u
- IEEE 802.1w
- IEEE 802.1p
- IEEE 802.3az
- IEEE 802.3at
- IEEE 802.3ab
- Copper Ethernet cabling technology
- 100BASE-TX
- 10BASE-T
- 1000BASE-T
- Virtual LAN Features
- Port-based VLAN
- Tagged VLAN
- VLAN support: Yes
- Port Mirroring: Yes
- Spanning Tree Protocol: Yes
- Supported cable types
- Cat4
- Cat5e
- Cat5
- Cat3
- Auto Detection: Yes
- Efficiency
- Buffer size: 512 KB
- Noise level: 45 dB
- Telnet: Yes
- Package contents
- Hook mounting kit: Yes
- Wires: Alternating Current
- Quick Start Guide: Yes
- User Manual: Yes
- Certificates
- Certificates of conformity
- Federal Communications Commission (FCC)
- CE
- Certificates of conformity
- Protocols
- IPv4 and IPv6 features: Dual stack IPv4/IPv6
- Ports and interfaces
- Basic RJ-45 Switching Number of Ethernet Ports: 16
- Basic Ethernet switching RJ-45 ports type: Gigabit Ethernet (10/100/1000)
- Number of SFP Module slots: 2
- Logistics data
- Harmonized System (HS) code: 85176990
- Data transfer
- Store-and-forward: Yes
- Jumbo Frame Compatible: Yes
- Address table size: 8000 entries
- Routing/switching capacity: 36 Gbit/s
- Forwarding speed: 1.488 Mpps
- Jumbo Frames Expansion: 9000
- Packet forwarding range (1 Gbps): 1488000 pps
- Packet forwarding range (10 Mbps): 14880 pps
- Packet forwarding range (100 Mbps): 148800 pps
- Power over Ethernet (PoE)
- PoE Support: Yes
- Total Power over Ethernet (PoE) budget: 374 W
- Power over Ethernet Plus (PoE +) ports: 16
- Power over Ethernet (PoE) power per port: 30 W
| Name | Details |
|---|---|
| Category | Computers and accessories |
| Producer | Intellinet |
| Colour | Black |
