INTELLINET Single-Mode Gigabit Ethernet Media Converter 507349
INTELLINET Single-Mode Gigabit Ethernet Media Converter 507349
INTELLINET Single-Mode Gigabit Ethernet Media Converter 507349
PRICE:
143,99
€
IN A WAREHOUSE
9 pcs
We'll ship this product in 9 days.
FREE EUROPE SHIPPING FROM 149 €!
30 DAYS FOR A RETURN!
Sign up and unlock up to 10% off!
- Features
- Housing material: Metal
- Product colour: Black
- Internal: No
- LED indicators: Yes
- Power
- External power adapter: Yes
- Operating voltage: 5 V
- Power consumption (max): 5 W
- Output current: 1.2 A
- Weight and dimensions
- Product height: 26 mm
- Product width: 70 mm
- Product weight: 180 g
- Product depth: 105 mm
- Operating conditions
- Relative humidity range: 10 - 90%
- Temperature range (storage): -45 - 70 °C
- Temperature range (operation): 0 - 50 °C
- Network
- Converter output interface: 1000Base-T
- Converter input interface: 1000Base-LX
- Fiber Ethernet cabling technology: 1000BASE‑LX
- Duplex data transmission: Full
- Communication standards
- IEEE 802.3u
- IEEE 802.3z
- IEEE 802.3ab
- IEEE 802.3
- Ethernet LAN data transfer rate
- 10 Mbit/s
- 100 Mbit/s
- 1000 Mbit/s
- Ethernet network interface type: Gigabit Ethernet
- Copper Ethernet cabling technology
- 100BASE-TX
- 10BASE-T
- 1000BASE-T
- Maximum data transfer rate: 1000 Mbit/s
- Performance
- Supported fibre cable diameters
- 8.3/125
- 8/125
- 8.7/125
- 10/125
- Single-mode fibre structure: Single
- Maximum transfer distance: 20000 m
- Sensitivity: -22 dBmW
- Tx power (maximum): -3 dBmW
- Tx power (minimum): -8 dBmW
- MTBF (Mean Time Between Failures): 100000 h
- Wavelength: 1310 nm
- Supported fibre cable diameters
- Packaging content
- User manual: Yes
- AC adapter: Yes
- Ports and interfaces
- Fibre optic connector: SC
- DC output jack: Yes
- Connectivity technology: Wired
- Number of Ethernet LAN ports (RJ-45): 1
- Number of ports: 1
- Logistics data
- Harmonized System (HS) code: 85176990
- Safety warning
- Warnings
- The product may contain small parts that could be dangerous to children.
- The product may generate heat; avoid contact with flammable materials.
- The product must be used in accordance with the user manual to avoid damage.
- Warnings
| Name | Details |
|---|---|
| Category | Computers and accessories |
| Producer | Intellinet |
| Department | Electronics |
