LANCOM CS-8132F-F2B Managed L2/L3 1U Black
LANCOM CS-8132F-F2B Managed L2/L3 1U Black
LANCOM CS-8132F-F2B Managed L2/L3 1U Black
PRICE:
55649,99
€
IN A WAREHOUSE
2 pcs
We'll ship this product in 9 days.
FREE EUROPE SHIPPING FROM 149 €!
30 DAYS FOR A RETURN!
Sign up and unlock up to 10% off!
- Design
- LEDs: Yes
- Product color: Black
- Number of fans: 3 fans
- Rack mounting options: Yes
- Layout: 1U
- Power
- AC input voltage: 100 - 240 V
- Power consumption (max): 310 W
- AC input frequency: 50/60 Hz
- Power source: AC
- Power supply included: Yes
- Weight and dimensions
- Product width: 446 mm
- Product depth: 480 mm
- Product weight: 7.44 kg
- Product height: 43.8 mm
- Security
- Encryption/Security
- SNMPv3
- SNMP
- SNMPv2
- IGMP snooping: Yes
- Loop protection: Yes
- Supports SSH/SSL: Yes
- Password protection: Yes
- Access Control List (ACL): Yes
- Static Port Protection: Yes
- DHCP functions
- DHCP server
- DHCP client
- DHCP relay
- Authentication type: IEEE 802.1x, RADIUS, TACACS+
- Encryption/Security
- Management features
- Quality of Service (QoS) Support: Yes
- Website management: Yes
- Configuring Location Settings (CLI): Yes
- MIB Support: MIB II, Bridge MIB, Interface MIB, SMON MIB, IGMP MIB, IEEE 802.3 MAU MIB
- Switch type: Managed
- Switch Layer: L2/L3
- System Event Report: Yes
- Traffic Classification: Yes
- ARP Inspection: Yes
- Working conditions
- Relative humidity range: 10 - 90%
- Temperature range (operation): 0 - 40 °C
- Heat emission: 1060 BTU/h
- Network
- Communication standards
- IEEE 802.1AX
- IEEE 802.1D
- IEEE 802.1Q
- IEEE 802.1w
- VLAN support: Yes
- IPv4 routes: 16000
- Full duplex: Yes
- 10G Support: Yes
- Virtual LAN Features
- Private VLAN
- Voice VLAN
- IPv6 routes: 16000
- IP forwarding: Yes
- Spanning Tree Protocol: Yes
- Frequency Limit: Yes
- Traffic Growth Control: Yes
- Rule-Based Routing: Yes
- Port Mirroring: Yes
- Flow Control Support: Yes
- Connection Aggregator: Yes
- Number of VLANs: 4093
- Communication standards
- Efficiency
- Internal memory capacity: 8.2 GB
- Noise level: 65 dB
- Processor clock speed: 1600 MHz
- Device software updates: Yes
- Built-in processor: Yes
- Memory type: DDR4-SDRAM
- Packaging data
- Package depth: 660 mm
- Package width: 540 mm
- Weight with packaging: 7.45 kg
- Package height: 180 mm
- Package contents
- User Manual: Yes
- Protocols
- Management protocols: SNMP
- Route Selection Protocol
- OSPFv3
- BGP4
- OSPFv2
- GARP VLAN Registration Protocol (GVRP): Yes
- Ports and interfaces
- Number of QSFP28 ports: 32
- Console port: RJ-45
- Power Connector: AC Input Socket
- Logistics data
- Country of origin: Taiwan
- Customs product code (TARIC): 85176200
- Data transfer
- Jumbo Frame Compatible: Yes
- Store-and-forward: Yes
- Performance: 32000 Gbit/s
- Packet buffer memory: 32 MB
- Jumbo Frames Extension: 12288
- Address table size: 32000 entries
- Multicast functions
- Multicast Support: Yes
