LevelOne 10x GE IGU-1071 Switch 8x 1GbE 2x 2.5GbE SFP sw (IGU-1071)
LevelOne 10x GE IGU-1071 Switch 8x 1GbE 2x 2.5GbE SFP sw (IGU-1071)
LevelOne 10x GE IGU-1071 Switch 8x 1GbE 2x 2.5GbE SFP sw (IGU-1071)
PRICE:
780,99
€
IN A WAREHOUSE
above 10 pcs
We'll ship this product in 8 days.
FREE EUROPE SHIPPING FROM 149 €!
30 DAYS FOR A RETURN!
Sign up and unlock up to 10% off!
- Technical details
- Gross pallet width: 120 cm
- Gross pallet length: 80 cm
- Collecting boxes (external) per pallet (air): 28 pcs.
- Pallet height (air): 164.4 cm
- Design
- LED diodes
- Power supply
- System
- IP protection class: IP40
- Product color: Black
- DIN rail mounting: Yes
- LED diodes
- Power
- Power consumption (max): 10 W
- Power source: DC
- Backup Power Supply (RPS) Support: Yes
- Power Supply Included: No
- Protection against sudden voltage increases
- Yes
- 6 kV
- DC input voltage: 12 - 58 V
- Number of power units: 2
- Weight and dimensions
- Product weight: 1.12 kg
- Product height: 158 mm
- Product width: 54 mm
- Product depth: 115 mm
- Security
- Encryption/Security
- HTTPS
- SSH
- IGMP snooping: Yes
- Authentication: MAC-based authentication, Port-based authentication
- Authentication type: IEEE 802.1x, RADIUS
- Access Control List (ACL): Yes
- DHCP functions: DHCP server
- IP-MAC-Port Binding: Yes
- Encryption/Security
- Management features
- Website management: Yes
- Quality of Service (QoS) Support: Yes
- Switch type: Managed
- ARP Inspection: Yes
- Switch Layer: L2+
- Configuring Location Settings (CLI): Yes
- System Event Report: Yes
- Working conditions
- Temperature range (storage): -40 - 85 °C
- Temperature range (operation): -40 - 75 °C
- Relative humidity range: 10 - 90%
- Permissible relative humidity: 5 - 95%
- Network
- Communication standards
- IEEE 802.1D
- IEEE 802.1ab
- IEEE 802.3
- IEEE 802.3ab
- IEEE 802.3x
- IEEE 802.1Q
- IEEE 802.1x
- IEEE 802.3z
- IEEE 802.3u
- IEEE 802.1s
- Copper Ethernet cabling technology
- 100BASE-TX
- 1000BASE-T
- 10BASE-T
- 1000BASE-X
- VLAN support: Yes
- Flow Control Support: Yes
- 10G Support: No
- Ethernet Ring Protection Switching (ERPS): Yes
- Port Mirroring: Yes
- Connection Aggregator: Yes
- Spanning Tree Protocol: Yes
- Communication standards
- Efficiency
- Device software updates: Yes
- No fan: Yes
- Packaging data
- Package width: 230 mm
- Packaging depth: 180 mm
- Weight with packaging: 1.38 kg
- Package height: 70 mm
- DIN rail included: Yes
- Strip included: Yes
- Package contents
- Quick Start Guide: Yes
- Cables: LAN (RJ-45)
- Certificates
- Certificates of conformity
- Federal Communications Commission (FCC)
- UKCA
- CE
- RoHS
- Certificates of conformity
- Protocols
- IP Source Protection (IPSG): Yes
- Ports and interfaces
- Number of SFP Module slots: 2
- Basic RJ-45 Switching Number of Ethernet Ports: 8
- Number of Gigabit Ethernet ports: 8
- Console port: RJ-45
- Basic Ethernet switching RJ-45 ports type: Gigabit Ethernet (10/100/1000)
- Other functions
- Remote administration: Y
- Logistics data
- Country of origin: China
- Harmonized System (HS) code: 851762
- Products in the main (outer) box: 12 pcs.
- Gross weight of the main (outer) housing: 17.5 kg
- Main (outer) case length: 375 mm
- Height of the standard (outer) box: 250 mm
- Width of the collection box (external): 440 mm
- Data transfer
- Routing/switching capacity: 26 Gbit/s
- Jumbo Frame Compatible: Yes
- Jumbo Frames Expansion: 10000
- Packet buffer memory: 12 MB
- Address table size: 16000 entries
- Transfer speed: 38.6 Mpps
- Power over Ethernet (PoE)
- PoE Support: No
| Name | Details |
|---|---|
| Producer | No name |
