LevelOne FE 5-port 1xSC MM 100Mbps switch
LevelOne FE 5-port 1xSC MM 100Mbps switch
LevelOne FE 5-port 1xSC MM 100Mbps switch
PRICE:
133,99
€
IN A WAREHOUSE
above 10 pcs
We'll ship this product in 8 days.
FREE EUROPE SHIPPING FROM 149 €!
30 DAYS FOR A RETURN!
Sign up and unlock up to 10% off!
- Design
- Product color
- Black
- Gray
- LED diodes
- Power supply
- Action
- Link
- Rack mounting options: No
- Housing material: Metal
- Stackable: No
- Product color
- Power
- Output current: 2.5 A
- Operating voltage: 5 V
- Power consumption (max): 6 W
- Weight and dimensions
- Product depth: 112 mm
- Product weight: 380 g
- Product width: 96 mm
- Product height: 30 mm
- Working conditions
- Temperature range (operation): 0 - 45 °C
- Temperature range (storage): -20 - 90 °C
- Relative humidity range: 10 - 90%
- Network
- Copper Ethernet cabling technology
- 10BASE-T
- 100BASE-FX
- 100BASE-TX
- Communication standards
- IEEE 802.3u
- IEEE 802.3x
- IEEE 802.3
- Auto MDI/MDI-X: Yes
- Auto-Negotiation: Yes
- Full duplex: Yes
- Supported cable types: Cat5
- 10G Support: No
- Copper Ethernet cabling technology
- Efficiency
- Maximum data transfer speed: 200 Mbit/s
- Buffer size: 384 KB
- Plug & Play Support: Yes
- Packaging data
- AC adapter: Yes
- Package width: 140 mm
- Packaging depth: 250 mm
- Weight with packaging: 540 g
- Package height: 55 mm
- Rubber feet: Yes
- Package contents
- Quick Start Guide: Yes
- Ports and interfaces
- Number of ports: 1
- Fiber optic connector
- ST
- SC
- Basic Ethernet switching RJ-45 ports type: Fast Ethernet (10/100)
- Basic RJ-45 Switching Number of Ethernet Ports: 4
- Power connector: DC-in jack
- Logistics data
- Country of origin: Taiwan
- Harmonized System (HS) code: 85176990
- Data transfer
- Store-and-forward: Yes
- Address table size: 1024 entries
- Packet forwarding range (100 Mbps): 148800 pps
- Packet forwarding range (10 Mbps): 14880 pps
- Power over Ethernet (PoE)
- PoE Support: No
- Fiber optic
- Fiber optic type: Multifunctional
- Fiber Ethernet cabling technology: 100BASE-FX
- Transmission distance (maximum): 2 km
| Name | Details |
|---|---|
| Producer | No name |
