LevelOne GB/L3 28-Port 19" 400W 10Gbps Managed PoE+ Switch
LevelOne GB/L3 28-Port 19" 400W 10Gbps Managed PoE+ Switch
LevelOne GB/L3 28-Port 19" 400W 10Gbps Managed PoE+ Switch
PRICE:
1320,99
€
IN A WAREHOUSE
above 10 pcs
We'll ship this product in 8 days.
FREE EUROPE SHIPPING FROM 149 €!
30 DAYS FOR A RETURN!
Sign up and unlock up to 10% off!
- Design
- Product color: Gray
- LEDs: Yes
- Reset button: Yes
- Rack mounting options: Yes
- Housing material: Metal
- Power
- AC input voltage: 100 - 240 V
- AC input frequency: 50 - 60 Hz
- Input current: 6 A
- Power consumption: 468.2 W
- Weight and dimensions
- Product width: 330 mm
- Product height: 44.5 mm
- Product weight: 4.48 kg
- Product depth: 440 mm
- Security
- Authentication type: RADIUS
- DHCP functions
- DHCP relay
- DHCP server
- DHCP snooping
- IGMP snooping: Yes
- Authentication: MAC-based authentication
- Access Control List (ACL): Yes
- IGMP Proxy: Yes
- Queue planning algorithms
- Priority queuing (PQ)
- Weighted Round Robin (WRR)
- Management features
- Quality of Service (QoS) Support: Yes
- Website management: Yes
- Switch Layer: L3
- ARP Inspection: Yes
- Switch type: Managed
- Configuring Location Settings (CLI): Yes
- System Event Report: Yes
- Traffic Classification: Yes
- Working conditions
- Permissible relative humidity: 5 - 95%
- Temperature range (storage): -40 - 70 °C
- Temperature range (operation): 0 - 45 °C
- Relative humidity range: 10 - 90%
- Network
- Communication standards
- IEEE 802.3
- IEEE 802.1ag
- IEEE 802.3af
- IEEE 802.3x
- IEEE 802.1D
- IEEE 802.1p
- IEEE 802.3az
- IEEE 802.3at
- IEEE 802.1w
- IEEE 802.1Q
- IEEE 802.3ah
- IEEE 802.1v
- IEEE 802.1x
- IEEE 802.3ad
- IEEE 802.1s
- IEEE 802.3z
- Data transfer speed via Ethernet LAN: 10,100,1000 Mbit/s
- Connection Aggregator: Yes
- Full duplex: Yes
- 10G Support: Yes
- Port Mirroring: Yes
- Traffic Growth Control: Yes
- Spanning Tree Protocol: Yes
- Frequency Limit: Yes
- Communication standards
- Efficiency
- Device software updates: Yes
- Plug & Play Support: Yes
- MTBF (Mean Time Between Failures): 150000 h
- Flash memory size: 32 MB
- Internal memory capacity: 512 MB
- Virtual stacking (pcs): 4
- Packaging data
- Package depth: 596 mm
- Rubber feet: Yes
- Package height: 80 mm
- Package width: 390 mm
- Weight with packaging: 6 kg
- Driver CD: Yes
- Package contents
- Quick Start Guide: Yes
- Hook mounting kit: Yes
- Wires: Alternating Current
- Certificates
- Certificates of conformity: RoHS
- Ports and interfaces
- Number of ports: 4
- Fiber optic connector: SFP+
- Number of SFP+ Module slots: 4
- Number of Gigabit Ethernet ports: 24
- Power Connector: AC Input Socket
- Basic RJ-45 Switching Number of Ethernet Ports: 24
- Basic Ethernet switching RJ-45 ports type: Gigabit Ethernet (10/100/1000)
- Logistics data
- Harmonized System (HS) code: 85176990
- Country of origin: China
- Data transfer
- Routing/switching capacity: 128 Gbit/s
- Address table size: 16000 entries
- Jumbo Frame Compatible: Yes
- Jumbo Frames Expansion: 12000
- Store-and-forward: Yes
- Static Route: Yes
- Packet buffer memory: 1.5 MB
- Forwarding speed: 95.232 Mpps
- Maximum data transfer rate: 10 Gbit/s
- Power over Ethernet (PoE)
- Total Power over Ethernet (PoE) budget: 400 W
- PoE Support: Yes
- Power over Ethernet (PoE) power per port: 30 W
- Multicast functions
- Multicast Support: Yes
