LevelOne GEL-2681 Managed L3 Gigabit Ethernet (10/100/1000) Network Switch Black
LevelOne GEL-2681 Managed L3 Gigabit Ethernet (10/100/1000) Network Switch Black
LevelOne GEL-2681 Managed L3 Gigabit Ethernet (10/100/1000) Network Switch Black
PRICE:
975,99
€
IN A WAREHOUSE
8 pcs
We'll ship this product in 8 days.
FREE EUROPE SHIPPING FROM 149 €!
30 DAYS FOR A RETURN!
Sign up and unlock up to 10% off!
- Design
- Reset button: Yes
- LED diodes
- Action
- Speed
- Link
- Product color: Black
- Security: LVD
- Rack mounting options: Yes
- Power
- AC input voltage: 100 - 240 V
- AC input frequency: 50 - 60 Hz
- Power consumption: 16.79 W
- Weight and dimensions
- Product weight: 2.6 kg
- Product depth: 211 mm
- Product width: 442 mm
- Product height: 44 mm
- Security
- Encryption/Security: 802.1x RADIUS
- Loop protection: Yes
- DHCP functions
- DHCP relay
- DHCP server
- DHCP snooping
- DHCP client
- BPDU Filtering/Protection: Yes
- Supports SSH/SSL: Yes
- IGMP Proxy: Yes
- IGMP snooping: Yes
- Access Control List (ACL): Yes
- Management features
- Website management: Yes
- Quality of Service (QoS) Support: Yes
- System Event Report: Yes
- Switch type: Managed
- Switch Layer: L3
- Working conditions
- Temperature range (storage): -20 - 75 °C
- Temperature range (operation): 0 - 45 °C
- Relative humidity range: 10 - 90%
- Permissible relative humidity: 10 - 90%
- Heat emission: 73.87 BTU/h
- Network
- Communication standards
- IEEE 802.3x
- IEEE 802.1D
- IEEE 802.3az
- IEEE 802.1s
- IEEE 802.1x
- IEEE 802.1Q
- IEEE 802.3ad
- IEEE 802.3z
- IEEE 802.3
- IEEE 802.1p
- IEEE 802.3u
- IEEE 802.1w
- IEEE 802.3ab
- Spanning Tree Protocol: Yes
- Copper Ethernet cabling technology
- 100BASE-TX
- 10BASE-T
- 1000BASE-T
- 10G Support: No
- VLAN support: Yes
- Virtual LAN Features
- Tagged VLAN
- Port-based VLAN
- Private VLAN
- Voice VLAN
- Flow Control Support: Yes
- Cable length measurement: Yes
- Traffic Growth Control: Yes
- Port Mirroring: Yes
- Communication standards
- Efficiency
- Device software updates: Yes
- MTBF (Mean Time Between Failures): 463931 h
- Flash memory size: 32 MB
- Buffer size: 512 KB
- Internal memory capacity: 128 MB
- Telnet: Yes
- sFlow: Yes
- Packaging data
- Package width: 300 mm
- Package depth: 520 mm
- Weight with packaging: 3 kg
- Package height: 90 mm
- Packaging type: Box
- Driver CD: Yes
- Package contents
- Wires
- Alternating current
- LAN (RJ-45)
- Quick Start Guide: Yes
- Hook mounting kit: Yes
- Wires
- Protocols
- Supported network protocols: IPv4/IPv6
- GARP VLAN Registration Protocol (GVRP): Yes
- Ports and interfaces
- Number of SFP Combo Ports: 2
- Basic RJ-45 Switching Number of Ethernet Ports: 24
- Basic Ethernet switching RJ-45 ports type: Gigabit Ethernet (10/100/1000)
- Console port: RJ-45
- Number of Gigabit Ethernet ports: 24
- Logistics data
- Country of origin: Taiwan
- Harmonized System (HS) code: 85176990
- Width of the collection box (external): 482 mm
- Main (outer) case length: 540 mm
- Products in the main (outer) box: 5 pcs.
- Height of the standard (outer) box: 324 mm
- Main (outer) housing gross weight: 16.2 kg
- Data transfer
- Routing/switching capacity: 52 Gbit/s
- Store-and-forward: Yes
- Jumbo Frame Compatible: Yes
- Address table size: 8000 entries
- Jumbo Frames Expansion: 9600
- Static Route: Yes
- Forwarding speed: 38.68 Mpps
- Power over Ethernet (PoE)
- PoE Support: No
