LevelOne Hilbert 26-Port Gigabit Smart Lite Switch - 24 x Gigabit RJ45 - 2 x Gigabit SFP (GES-2126)
LevelOne Hilbert 26-Port Gigabit Smart Lite Switch - 24 x Gigabit RJ45 - 2 x Gigabit SFP (GES-2126)
LevelOne Hilbert 26-Port Gigabit Smart Lite Switch - 24 x Gigabit RJ45 - 2 x Gigabit SFP (GES-2126)
PRICE:
286,99
€
IN A WAREHOUSE
above 10 pcs
We'll ship this product in 8 days.
FREE EUROPE SHIPPING FROM 149 €!
30 DAYS FOR A RETURN!
Sign up and unlock up to 10% off!
- Technical details
- Pallet height (air): 159.4 cm
- Collective boxes (external) per pallet (air): 20 pcs.
- Gross pallet width: 120 cm
- Gross pallet length: 80 cm
- Design
- LED diodes
- Action
- Power supply
- Link
- System
- Rack mounting options: Yes
- Product color: Black
- LED diodes
- Power
- Protection against sudden voltage increases
- 8 kV
- Yes
- AC input voltage: 100 - 240 V
- Power source: AC
- Power consumption (max): 18 W
- AC input frequency: 50 - 60 Hz
- Protection against sudden voltage increases
- Weight and dimensions
- Product weight: 1.85 kg
- Product depth: 190 mm
- Product height: 44.5 mm
- Product width: 440 mm
- Security
- IGMP snooping: Yes
- Management features
- Switch Layer: L2
- Switch type: Managed
- Website management: Yes
- Quality of Service (QoS) Support: Yes
- Working conditions
- Heat emission: 61.42 BTU/h
- Temperature range (storage): -40 - 70 °C
- Temperature range (operation): 0 - 45 °C
- Permissible relative humidity: 5 - 95%
- Relative humidity range: 10 - 90%
- Network
- MAC address auto-learning supported: Yes
- Virtual LAN Features
- Tagged VLAN
- Port-based VLAN
- Traffic Growth Control: Yes
- MAC address auto-aging supported: Yes
- Flow Control Support: Yes
- Port Mirroring: Yes
- Connection Aggregator: Yes
- Frequency Limit: Yes
- VLAN support: Yes
- Communication standards
- IEEE 802.3z
- IEEE 802.1Q
- IEEE 802.3u
- IEEE 802.3ab
- IEEE 802.1p
- IEEE 802.3x
- IEEE 802.3
- IEEE 802.3az
- Copper Ethernet cabling technology
- 100BASE-TX
- 1000BASE-T
- 10BASE-T
- 10G Support: No
- Number of VLANs: 32
- Full duplex: Yes
- Efficiency
- No fan: Yes
- Noise level: 0 dB
- Flash memory size: 2 MB
- MTBF (Mean Time Between Failures): 43800 h
- Packaging data
- Packaging type: Box
- Weight with packaging: 2.45 kg
- Package depth: 270 mm
- Package height: 85 mm
- Package width: 503 mm
- Package contents
- Hook mounting kit: Yes
- Quick Start Guide: Yes
- Wires: Alternating Current
- Certificates
- Certificates of conformity
- CE
- RoHS
- Certificates of conformity
- Ports and interfaces
- Number of Gigabit Ethernet ports: 24
- Basic RJ-45 Switching Number of Ethernet Ports: 24
- Number of SFP Module slots: 2
- Basic Ethernet switching RJ-45 ports type: Gigabit Ethernet (10/100/1000)
- Logistics data
- Net weight in bulk packaging: 750 g
- Country of origin: China
- Products in the main (outer) box: 4 pcs.
- Main (outer) housing gross weight: 10.6 kg
- Main (outer) case length: 360 mm
- Height of the standard (outer) box: 290 mm
- Width of the collection box (external): 515 mm
- Data transfer
- Number of rounds: 4
- Jumbo Frames Expansion: 9000
- Packet buffer memory: 4.1 MB
- Routing/switching capacity: 52 Gbit/s
- Jumbo Frame Compatible: Yes
- Address table size: 8000 entries
- Power over Ethernet (PoE)
- PoE Support: No
- Multicast functions
- Multicast Support: Yes
- Sustainable development
- Sustainability: Yes
| Name | Details |
|---|---|
| Producer | No name |
