LevelOne Hilbert 8-Port Gigabit PoE Smart Lite Switch - 802.3at/af PoE - 8 PoE Outputs - 112.8W Power Budget
LevelOne Hilbert 8-Port Gigabit PoE Smart Lite Switch - 802.3at/af PoE - 8 PoE Outputs - 112.8W Power Budget
LevelOne Hilbert 8-Port Gigabit PoE Smart Lite Switch - 802.3at/af PoE - 8 PoE Outputs - 112.8W Power Budget
PRICE:
214,99
€
IN A WAREHOUSE
above 10 pcs
We'll ship this product in 8 days.
FREE EUROPE SHIPPING FROM 149 €!
30 DAYS FOR A RETURN!
Sign up and unlock up to 10% off!
- Technical details
- Gross pallet length: 80 cm
- Gross pallet width: 120 cm
- Pallet height (air): 158.4 cm
- Collective boxes (external) per pallet (air): 18 pcs.
- Design
- Rack mounting options: No
- LED diodes
- Link
- Action
- PoE
- Product color: Black
- Power
- Power source: DC/PoE
- Power consumption (max): 120 W
- Protection against sudden voltage increases
- Yes
- 8 kV
- Power supply included: Yes
- DC input voltage: 54 V
- Input current: 2.2 A
- Weight and dimensions
- Product height: 29 mm
- Product depth: 95 mm
- Product width: 160 mm
- Product weight: 400 g
- Security
- IGMP snooping: Yes
- Management features
- Quality of Service (QoS) Support: Yes
- Website management: Yes
- Switch Layer: L2
- Switch type: Managed
- Working conditions
- Temperature range (operation): 0 - 45 °C
- Permissible relative humidity: 5 - 95%
- Temperature range (storage): -40 - 70 °C
- Relative humidity range: 10 - 90%
- Heat emission: 27.3 BTU/h
- Network
- Number of VLANs: 32
- Full duplex: Yes
- Auto MDI/MDI-X: Yes
- VLAN support: Yes
- Half-duplex: Yes
- Virtual LAN Features: Tagged VLAN
- Port Mirroring: Yes
- Auto-Negotiation: Yes
- Frequency Limit: Yes
- MAC address auto-aging supported: Yes
- Flow Control Support: Yes
- Traffic Growth Control: Yes
- MAC address auto-learning supported: Yes
- Connection Aggregator: Yes
- Communication standards
- IEEE 802.3az
- IEEE 802.3at
- IEEE 802.3u
- IEEE 802.3
- IEEE 802.1Q
- IEEE 802.3af
- IEEE 802.3x
- IEEE 802.1p
- IEEE 802.3ab
- Efficiency
- Noise level: 0 dB
- Flash memory size: 2 MB
- MTBF (Mean Time Between Failures): 43800 h
- No fan: Yes
- Packaging data
- AC adapter: Yes
- Packaging depth: 230 mm
- Package height: 65 mm
- Package width: 310 mm
- Weight with packaging: 1.3 kg
- Packaging type: Box
- Package contents
- Wires: Alternating Current
- Certificates
- Certificates of conformity
- RoHS
- CE
- Certificates of conformity
- Ports and interfaces
- Basic RJ-45 Switching Number of Ethernet Ports: 8
- Basic Ethernet switching RJ-45 ports type: Gigabit Ethernet (10/100/1000)
- Number of Gigabit Ethernet ports: 8
- Logistics data
- Main (outer) housing gross weight: 13.6 kg
- Main (outer) case length: 330 mm
- Height of the standard (outer) box: 480 mm
- Products in the main (outer) box: 10 pcs.
- Width of the collection box (external): 350 mm
- Country of origin: China
- Net weight in bulk packaging: 600 g
- Data transfer
- Address table size: 4000 entries
- Jumbo Frame Compatible: Yes
- Packet buffer memory: 1.5 MB
- Routing/switching capacity: 16 Gbit/s
- Jumbo Frames Expansion: 9000
- Number of rounds: 4
- Power over Ethernet (PoE)
- Power over Ethernet (PoE) power per port: 30 W
- Total Power over Ethernet (PoE) budget: 112.8 W
- PoE Support: Yes
- Power over Ethernet Plus (PoE +) ports: 8
- Multicast functions
- Multicast Support: Yes
- Sustainable development
- Sustainability: Yes
