- Technical details
- Gross pallet width: 120 cm
- Gross pallet length: 80 cm
- Collective boxes (external) per pallet (air): 14 pcs.
- Pallet height (air): 177.6 cm
- Design
- Rack mounting options: Yes
- IP protection class: IP40
- Product color: Black
- LED diodes
- USB
- System
- Power supply
- Power
- Power supply included: Yes
- AC input voltage: 100 - 240 V
- AC input frequency: 50/60 Hz
- Protection against sudden voltage increases
- Yes
- 6 kV
- Backup Power Supply (RPS) Support: Yes
- Power consumption (max): 36 W
- Power source: AC
- DC input voltage: 36 - 75 V
- Weight and dimensions
- Product depth: 45 mm
- Product height: 280 mm
- Product width: 440 mm
- Product weight: 4.14 kg
- Security
- Authentication: MAC-based authentication, Port-based authentication
- Access Control List (ACL): Yes
- MAC address filtering: Yes
- Encryption/Security
- HTTPS
- SSH
- MAC address entries
- Static MAC address entries
- Dynamic MAC address entries
- Packet Filtering: Y
- Queue Planning Algorithms: Weighted Round Robin (WRR)
- Management features
- Switch Layer: L2+
- Switch type: Managed
- System Event Report: Yes
- Website management: Yes
- Quality of Service (QoS) Support: Yes
- Working conditions
- Temperature range (storage): -40 - 85 °C
- Permissible relative humidity: 5 - 95%
- Temperature range (operation): -40 - 80 °C
- Relative humidity range: 10 - 90%
- Network
- VLAN support: Yes
- 10G Support: No
- Flow Control Support: Yes
- Traffic Growth Control: Yes
- Port Channel System: Yes
- Copper Ethernet cabling technology
- 100BASE-TX
- 1000BASE-T
- 100BASE-X
- 10BASE-T
- Communication standards
- IEEE 802.1D
- IEEE 802.3
- IEEE 802.3ab
- IEEE 802.3x
- IEEE 802.1Q
- IEEE 802.3z
- IEEE 802.3u
- IEEE 802.1x
- IEEE 802.1ab
- IEEE 802.1s
- Port Mirroring: Yes
- Frequency Limit: Yes
- Virtual LAN Features
- Protocol-based VLAN
- Stacked VLAN
- VLAN mapping
- MAC address-based VLAN
- Ethernet Ring Protection Switching (ERPS): Yes
- Spanning Tree Protocol: Yes
- Efficiency
- MTBF (Mean Time Between Failures): 200000 h
- No fan: Yes
- Packaging data
- Package width: 525 mm
- Package height: 95 mm
- Weight with packaging: 5.29 kg
- Package depth: 390 mm
- Strip included: Yes
- Package contents
- Hook mounting kit: Yes
- Wires
- Alternating current
- LAN (RJ-45)
- Quick Start Guide: Yes
- Certificates
- Certificates of conformity
- Federal Communications Commission (FCC)
- UKCA
- CE
- RoHS
- Certificates of conformity
- Protocols
- IPv4 and IPv6 features: IPv4/IPv6 access-control list (ACL)
- IP Source Protection (IPSG): Yes
- Ports and interfaces
- Number of SFP Combo Ports: 8
- Number of SFP Module slots: 20
- Console port: RJ-45
- Basic Ethernet Switching RJ-45 Ports Type: No
- Number of USB 2.0 ports: 1
- Logistics data
- Country of origin: China
- Products in the main (outer) box: 4 pcs.
- Main (outer) housing gross weight: 22.5 kg
- Main (outer) box length: 400 mm
- Harmonized System (HS) code: 851762
- Height of the standard (outer) box: 408 mm
- Width of the collection box (external): 535 mm
- Data transfer
- Routing/switching capacity: 68 Gbit/s
- Jumbo Frame Compatible: Yes
- Address table size: 16000 entries
- Packet buffer memory: 12 MB
- Jumbo Frames Expansion: 10000
- Forwarding speed: 101.1 Mpps
- Power over Ethernet (PoE)
- PoE Support: No
