LevelOne omnidirectional/IP65 5/8dBi 2.4/5GHz antenna
LevelOne omnidirectional/IP65 5/8dBi 2.4/5GHz antenna
LevelOne omnidirectional/IP65 5/8dBi 2.4/5GHz antenna
PRICE:
148,99
€
IN A WAREHOUSE
above 10 pcs
We'll ship this product in 8 days.
FREE EUROPE SHIPPING FROM 149 €!
30 DAYS FOR A RETURN!
Sign up and unlock up to 10% off!
- Characteristics
- Product color: White
- Connector type: Female
- Antenna type: Omnidirectional antenna
- Antenna plug type: N-Type
- Voltage Standing Wave Ratio (VSRW): 2
- Polarization: Vertical polarization
- Weight and dimensions
- Product weight: 860 g
- Product depth: 203 mm
- Product width: 22 mm
- Product height: 22 mm
- Working conditions
- Temperature range (operation): -30 - 60 °C
- Relative humidity range: 0 - 95%
- Efficiency
- Frequency band: 2.4 - 5 GHz
- Communication standards
- IEEE 802.11ac
- IEEE 802.11b
- IEEE 802.11n
- IEEE 802.11a
- IEEE 802.11g
- Antenna gain level (max): 8 dBi
- Antenna range (5 GHz): 8 dBi
- Vertical beamwidth (2.4 GHz): 51.7°
- Gain factor: 5/8 dBi
- Antenna range (2.4 GHz): 5 dBi
- Horizontal beamwidth (2.4 GHz): 360°
- Vertical beamwidth (5 GHz): 27.7°
- Impedance: 50 Ω
- Horizontal beamwidth (5 GHz): 360°
- Packaging data
- Weight with packaging: 192 g
- Package width: 70 mm
- Packaging type: Blister
- Package depth: 60 mm
- Package height: 265 mm
- Package contents
- Number of pieces: 1
- Logistics data
- Country of origin: Taiwan
- Harmonized System (HS) code: 85177100
- Gross weight of the main (outer) housing: 11 kg
- Main (outer) case length: 560 mm
- Height of the standard (outer) box: 290 mm
- Width of the collection box (external): 480 mm
- Box capacity (external): 50 cm³
- Products in the main (outer) box: 50 pcs.
| Name | Details |
|---|---|
| Producer | No name |
