Monitor DS-D5024F2-BV2S
Monitor DS-D5024F2-BV2S
Sign up and unlock up to 10% off!
- Design
- Product color: Black
- Housing material: Plastic
- Market positioning: Business
- Frameless design: Yes
- Front cover: Black
- Detachable base: Yes
- Leg color: Black
- Power
- Input current: 2 A
- Power consumption: 24 W
- Power consumption in standby mode: 0.3 W
- Power supply type: External
- Energy efficiency class (HDR): Not available
- Energy efficiency class (SDR): E
- Energy consumption (SDR) per 1000 hours: 16.1 kWh
- Weight and dimensions
- Device height (with base): 399.9 mm
- Device depth (with base): 164.7 mm
- Device width (with base): 539.7 mm
- Depth (without base): 43.5 mm
- Weight (with base): 2.85 kg
- Bezel width (top): 2 mm
- Width (without base): 539.7 mm
- Frame width (side): 2 mm
- Height (without stand): 327.3 mm
- Frame width (bottom): 2.35 cm
- Working conditions
- Permissible relative humidity: 10 - 90%
- Temperature range (storage): -20 - 60 °C
- Relative humidity range: 20 - 90%
- Temperature range (operation): 0 - 40 °C
- Efficiency
- Low blue light technology: Yes
- Working hours (hours/days): 24/7
- Packaging data
- Packaging type: Box
- Weight with packaging: 3.85 kg
- Package height: 116 mm
- Package depth: 445 mm
- Package width: 652 mm
- Package contents
- User Manual: Yes
- Cables: HDMI
- Base Included: Yes
- Power supply included: Yes
- Display
- Screen diagonal: 23.8"
- Resolution: 1920 x 1080 px
- Response time (typical): 7 ms
- Display brightness (typical): 250 cd/m²
- HD type: Full HD
- Screen shape: Flat
- Native aspect ratio: 16:9
- LED backlight: Yes
- Spot size: 0.2745 x 0.2745 mm
- Viewing angle (vertical): 178°
- Horizontal viewing angle: 178°
- Display technology: LED
- Backlight type: Edge LED
- Matrix type: VA
- Contrast ratio (typical): 4000:1
- Display colors: 16.7 million colors
- Color gamut standard: NTSC
- Touchscreen: No
- Haze index: 25%
- Color palette: 72%
- SmartResponse: 8 ms
- Color depth: 8 bit
- Maximum refresh rate: 100 Hz
- Screen diagonal length (cm): 60.5 cm
- Multimedia
- Output power (RMS): 4 W
- Built-in speakers: Yes
- Built-in camera: No
- Number of speakers: 2
- Ergonomics
- VESA Standard: Yes
- Height adjustment: No
- Panel mounting interface: 75 x 75 mm
- Plug & Play Support: Yes
- Ports and interfaces
- HDMI version: 1.4
- Built-in USB hub: No
- Number of HDMI ports: 1
- Number of VGA (D-Sub) ports: 1
- HDMI: Yes
- Audio input: Yes
- Other functions
- Active screen area (W x H): 527.04 x 296.46 mm
| Name | Details |
|---|---|
| Producer | Hikvision |
