Qnap TS-432PXU-2G, 1U, 4 x 2.5"/3.5" SATA, Annapurna Labs Alpine AL324 1.7GH, 2GB DDR4 UDIMM (Max. 16GB), 2 x 10GbE SFP+, 2 x 2.5GbE, Single PSU (not upgradeable to RP)

Name: Qnap TS-432PXU-2G, 1U, 4 x 2.5"/3.5" SATA, Annapurna Labs Alpine AL324 1.7GH, 2GB DDR4 UDIMM (Max. 16GB), 2 x 10GbE SFP+, 2 x 2.5GbE, Single PSU (not upgradeable to RP)
SKU: TS-432PXU-2G
Price: 1333.99 EUR
Availability: InStock

Qnap TS-432PXU-2G, 1U, 4 x 2.5"/3.5" SATA, Annapurna Labs Alpine AL324 1.7GH, 2GB DDR4 UDIMM (Max. 16GB), 2 x 10GbE SFP+, 2 x 2.5GbE, Single PSU (not upgradeable to RP)

2. Qnap TS-432PXU-2G, 1U, 4 x 2.5"/3.5" SATA, Annapurna Labs Alpine AL324 1.7GH, 2GB DDR4 UDIMM (Max. 16GB), 2 x 10GbE SFP+, 2 x 2.5GbE, Single PSU (not upgradeable to RP)

3. Qnap TS-432PXU-2G, 1U, 4 x 2.5"/3.5" SATA, Annapurna Labs Alpine AL324 1.7GH, 2GB DDR4 UDIMM (Max. 16GB), 2 x 10GbE SFP+, 2 x 2.5GbE, Single PSU (not upgradeable to RP)

4. Qnap TS-432PXU-2G, 1U, 4 x 2.5"/3.5" SATA, Annapurna Labs Alpine AL324 1.7GH, 2GB DDR4 UDIMM (Max. 16GB), 2 x 10GbE SFP+, 2 x 2.5GbE, Single PSU (not upgradeable to RP)

5. Qnap TS-432PXU-2G, 1U, 4 x 2.5"/3.5" SATA, Annapurna Labs Alpine AL324 1.7GH, 2GB DDR4 UDIMM (Max. 16GB), 2 x 10GbE SFP+, 2 x 2.5GbE, Single PSU (not upgradeable to RP)

6. Qnap TS-432PXU-2G, 1U, 4 x 2.5"/3.5" SATA, Annapurna Labs Alpine AL324 1.7GH, 2GB DDR4 UDIMM (Max. 16GB), 2 x 10GbE SFP+, 2 x 2.5GbE, Single PSU (not upgradeable to RP)

Qnap TS-432PXU-2G, 1U, 4 x 2.5"/3.5" SATA, Annapurna Labs Alpine AL324 1.7GH, 2GB DDR4 UDIMM (Max. 16GB), 2 x 10GbE SFP+, 2 x 2.5GbE, Single PSU (not upgradeable to RP)

PRICE: 1333,99 €

QUANTITY BUY NOW

N/A

IN A WAREHOUSE LAST ITEM!

Goods available on request - delivery time to 7 working days

FREE EUROPE SHIPPING FROM 149 €! 30 DAYS FOR A RETURN!

Sign up and unlock up to 10% off!

FIND OUT MORE

REGISTRATION

Processor
- Processor manufacturer: Annapurna Labs
- Processor model: Alpine AL-324
- Number of processor cores: 4
- Processor clock speed: 1.7 GHz
- Processor Type: Annapurna Labs
Memory
- Memory slots: 1
- Maximum RAM: 16 GB
- Memory type: UDIMM
- Flash memory size: 512 MB
- RAM type: DDR4
- RAM: 2 GB
Design
- Number of fans: 2 fans
- Housing: Rack (1U)
- Fan bowl diameter: 4 cm
- Product color: Black
- Cooling type: Active
- LED diodes
  - HDD
  - Status
  - LAN
Power
- Power consumption: 39,558 W
- Power Location: Built-in
- Number of power units: 1
- Power supply power: 250 W
- Fan current: 12V
- AC input voltage: 100 - 240 V
Weight and dimensions
- Package depth: 665 mm
- Product width: 439 mm
- Product height: 44 mm
- Product depth: 499 mm
- Package height: 175 mm
- Product weight: 6.53 kg
- Weight with packaging: 9.34 kg
- Package width: 625 mm
Working conditions
- Relative humidity range: 5 - 95%
- Temperature range (operation): 0 - 40 °C
Network
- Ethernet LAN support (max): 10000 Mbit/s
- Balance Balance System: Yes
- Supported WLAN adapter: Yes
- iSCSI Support: Yes
- Jumbo Frame Compatible: Yes
- Supported network protocols: PPTP, L2TP/IPSec, OpenVPN, QBelt
- DHCP server: Yes
- Connection Aggregator: Yes
- Wired LAN: Yes
- Wake-On-LAN: Yes
- Data transfer speed via Ethernet LAN
  - 100 Mbps
  - 1000 Mbps
  - 10000 Mbps
  - 2500 Mbps
- DHCP Client: Yes
Efficiency
- Universal Plug and Play (UPnP): Yes
- USB Copy Function: Yes
- Buzzer: Yes
- Photo: Yes
- Backup Features
  - iSCSI LUN
  - Cloud
- Supported browsers: Mozilla Firefox, Microsoft Internet Explorer 10+, Apple Safari 7+, Google Chrome
- Device class: Small and Medium Business
- Hot Reserve Elements: Yes
- Access Control List (ACL): Yes
- System log: Yes
- Multilingual support: Yes
- Built-in FTP server: Yes
- Backup function: Yes
- Built-in switch: Yes
- SMART Support: Yes
- Sharing Folder: CIFS/SMB
- Model: US
- Encryption/Security
  - FIPS 140-2
  - HTTPS
  - 256-bit AES
  - SSH
  - SSL/TLS
- Website management: Yes
- Reset button: Yes
- Noise level: 38 dB
Package contents
- Wires
  - Alternating current
  - LAN (RJ-45)
- Number of screws: 28
- Packaging type: Box
Software
- Supported Mac operating systems
  - Mac OS X 10.11 El Capitan
  - Mac OS X 10.14 Mojave
  - Mac OS X 10.12 Sierra
  - Mac OS X 10.15 Catalina
  - Mac OS X 10.10 Yosemite
  - Mac OS X 10.13 High Sierra
- Supported server operating systems
  - Windows Server 2008 R2
  - Windows Server 2016
  - Windows Server 2012 R2
  - Windows Server 2012
  - Windows Server 2019
- Linux operating systems supported: Yes
- Operating system version: 5.0.0
- Installed operating system: QNAP Turbo System
- Supported Windows operating systems
  - Windows 10
  - Windows 8
  - Windows 7
Data carrier
- Bad Block Scanning: Yes
- Online RAID expansion: Yes
- RAID Rebuild: Yes
- Online RAID migration: Yes
- Installed storage device: No
- Disk capacity: 0 GB
- Hot-swap bay: Yes
- Supported storage drive sizes
  - 2.5
  - 3.5
- Types of installed drives: No
- Number of supported storage drive sizes: 4
- Total installed memory capacity: 0 TB
- Supported file systems
  - FAT32
  - ext4
  - HFS+
  - ext3
  - NTFS
- RAID Service: Yes
- Supported hard drive interfaces: SATA II, SATA III
- Supported drive types: HDD & SSD
- RAID levels
  - 10
  - 5
  - 6
  - 1
  - 0
  - JBOD
Ports and interfaces
- Number of USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports: 4
- Number of ports: 2
- Fiber optic connector: SFP+
- USB port: Yes
- Number of Ethernet LAN ports (RJ-45): 2
Other functions
- Warranty period: 3 years
Logistics data
- Harmonized System (HS) code: 84714100
Safety warning
- Warnings
  - Do not throw this device into regular trash. This product requires special disposal.
  - Avoid contact with liquids.
  - Do not disassemble the device yourself.
