Shuttle DB860 Barebones PC Size 1.35L Black Intel B860 LGA 1851 (Socket V1)
Shuttle DB860 Barebones PC Size 1.35L Black Intel B860 LGA 1851 (Socket V1)
Shuttle DB860 Barebones PC Size 1.35L Black Intel B860 LGA 1851 (Socket V1)
PRICE:
666,99
€
IN A WAREHOUSE
above 10 pcs
We'll ship this product in 8 days.
FREE EUROPE SHIPPING FROM 149 €!
30 DAYS FOR A RETURN!
Sign up and unlock up to 10% off!
- Technical details
- Certificates of conformity
- BSMI
- CE
- RCM
- RoHS
- Federal Communications Commission (FCC)
- ETL
- CB
- VCCI
- Certificates of conformity
- Processor
- Built-in processor: No
- Graphics
- Built-in graphics card: Yes
- Memory
- Without ECC: Yes
- Maximum memory capacity: 96 GB
- Supported memory clock speeds: 5600 MHz
- Built-in internal memory: No
- Memory voltage: 1.1 V
- ECC Correction: No
- Memory Channel Support: Dual Channel
- Number of memory slots: 2
- Memory slot type: SO-DIMM
- Supported memory types: DDR5-SDRAM
- Design
- Product color: Black
- LED diodes
- Power supply
- HDD
- Cable lock slot type: Kensington
- Kensington Lock: Yes
- Product type: Mini barebones computer
- VESA Standard: Yes
- Housing: PC size 1.35L
- Cooling type: Active
- Housing material: Metal
- Power
- AC adapter output current: 9.23 A
- Power supply type: External power supply
- Number of power units: 1
- AC input frequency: 50/60 Hz
- AC input voltage: 100 - 240 V
- AC adapter output voltage: 19V
- Power supply: 180 W
- Weight and dimensions
- Weight with packaging: 2.1 kg
- Product weight: 1.3 kg
- Product width: 165 mm
- Product depth: 190 mm
- Product height: 43 mm
- Working conditions
- Temperature range (operation): 0 - 50 °C
- Relative humidity range: 10 - 90%
- Network
- LAN controller
- Intel® I219
- Intel I226
- Wi-Fi: No
- Wired LAN: Yes
- LAN controller
- Efficiency
- Motherboard Layout: Intel B860
- Trusted Platform Module (TPM): Yes
- Audio chip: Realtek ALC888S
- Audio output channels: 2.0 ch.
- TPM version: 2.0
- BIOS Type: EFI AMI
- Number of supported processors: 1
- Processor socket: LGA 1851 (Socket V1)
- Package contents
- Power cord included: Yes
- AC adapter: Yes
- Quick Start Guide: Yes
- Drivers included: Yes
- Audio
- Built-in speakers: No
- Software
- Linux operating systems supported: Yes
- Supported Windows operating systems: Windows 11
- Data carrier
- Supported drive types: HDD & SSD
- Installed storage device: No
- NVMe: Yes
- Storage drive interface: M.2, PCI Express, SATA
- SSD type: M.2
- Number of supported storage drive sizes: 2
- Supported storage drive sizes: 2.5
- Ports and interfaces
- DC output socket: Yes
- Serial communication ports: 2
- Microphone: Yes
- Number of USB4 Gen 2x2 ports: 1
- Number of HDMI ports: 2
- HDMI version: 2.0/2.1
- Number of USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports: 4
- Headphone outputs: 1
- DisplayPort version: 1.4a
- Number of Ethernet LAN ports (RJ-45): 2
- DisplayPort Quantity: 1
- Number of USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports: 2
- Number of USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports: 1
- Logistics data
- Harmonized System (HS) code: 84733080
- Sustainable development
- Environmental certificate (sustainable development)
- ErP
- ENERGY STAR
- Environmental certificate (sustainable development)
