Switch TP-LINK TL-SG2016P
Switch TP-LINK TL-SG2016P
Switch TP-LINK TL-SG2016P
PRICE:
291,99
€
IN A WAREHOUSE
above 10 pcs
We'll ship this product in 8 days.
FREE EUROPE SHIPPING FROM 149 €!
30 DAYS FOR A RETURN!
Sign up and unlock up to 10% off!
- Design
- Rack mounting options: Yes
- LED diodes
- Power supply
- PoE
- System
- Product color: Black
- Power
- Power consumption (max): 146.5 W
- Power source: DC/PoE
- DC input voltage: 53.5 V
- Weight and dimensions
- Product width: 286 mm
- Product height: 25.4 mm
- Product depth: 111.7 mm
- Security
- MAC address entries
- Static MAC address entries
- Dynamic MAC address entries
- Queue planning algorithms
- Weighted Round Robin (WRR)
- SP
- BPDU Filtering/Protection: Yes
- Authentication: Guest VLAN, MAC-based authentication, Port-based authentication
- Supports SSH/SSL: Yes
- IGMP snooping: Yes
- IP-MAC-Port Binding: Yes
- DHCP functions
- DHCPv6 snooping
- DHCP relay
- DHCPv6 client
- DHCP snooping
- Access Control List (ACL): Yes
- MAC address filtering: Yes
- Encryption/Security
- SNMP
- SNMPv2
- EAP-MD5
- SSL/TLS
- SNMPv3
- HTTPS
- SSH
- MAC address entries
- Management features
- Cloud-managed: Yes
- ARP Inspection: Yes
- System Event Report: Yes
- Configuring Location Settings (CLI): Yes
- Quality of Service (QoS) Support: Yes
- Switch type: Managed
- Switch Layer: L2/L2+
- MIB support: RFC1213, RFC1493, RFC2674, RFC2620, RFC2618, RFC2925, RFC1757
- Website management: Yes
- Working conditions
- Temperature range (operation): 0 - 40 °C
- Temperature range (storage): -40 - 70 °C
- Heat emission: 499.98 BTU/h
- Relative humidity range: 10 - 90%
- Permissible relative humidity: 5 - 90%
- Network
- Frequency Limit: Yes
- Spanning Tree Protocol: Yes
- VLAN support: Yes
- Auto-Negotiation: Yes
- Copper Ethernet cabling technology
- 1000BASE-T
- 10BASE-T
- 100BASE-TX
- Auto MDI/MDI-X: Yes
- Traffic Growth Control: Yes
- Port Mirroring: Yes
- Number of VLANs: 4000
- Connection Aggregator: Yes
- Flow Control Support: Yes
- 10G Support: No
- Virtual LAN Features
- Multicast VLAN
- Tagged VLAN
- Voice VLAN
- Communication standards
- IEEE 802.3af
- IEEE 802.3x
- IEEE 802.3i
- IEEE 802.1p
- IEEE 802.1D
- IEEE 802.11w
- IEEE 802.3at
- IEEE 802.3ab
- IEEE 802.1s
- IEEE 802.3ad
- IEEE 802.1x
- IEEE 802.1Q
- Data transfer speed via Ethernet LAN: 10,100,1000 Mbit/s
- Efficiency
- No fan: Yes
- Device software updates: Yes
- Package contents
- Wires: Alternating Current
- User Manual: Yes
- Protocols
- GARP VLAN Registration Protocol (GVRP): Yes
- IPv4 and IPv6 features: Dual stack IPv4/IPv6
- Supported network protocols: ICMP, TCPv6, UDPv6, Ping6, Tracert6, Telnet (v6), TFTP, TCP/UDP, DSCP/IP, SSLv3, TLS 1.2
- Ports and interfaces
- Basic RJ-45 Switching Number of Ethernet Ports: 16
- Basic Ethernet switching RJ-45 ports type: Gigabit Ethernet (10/100/1000)
- Power connector: DC-in jack
- Data transfer
- Forwarding speed: 23.81 Mpps
- Number of rounds: 8
- Jumbo Frames Expansion: 9000
- Routing/Switching Throughput: 32 Gbit/s
- Address table size: 8000 entries
- Packet buffer memory: 4.1 MB
- Jumbo Frame Compatible: Yes
- Power over Ethernet (PoE)
- PoE Support: Yes
- Power over Ethernet Plus (PoE +) ports: 8
- Total Power over Ethernet (PoE) budget: 120 W
- Multicast functions
- Multicast Listener Discovery (MLD) snooping: MLD v1, MLD v2
- Multicast Support: Yes
- Safety warning
- Warnings
- Do not open the casing or attempt to repair it yourself.
- Ensure the device is adequately ventilated during operation.
- This product is not suitable for disposal in regular trash. Please dispose of used electronic equipment at a recycling center in accordance with local regulations.
- Warnings
| Name | Details |
|---|---|
| Producer | TP-LINK |
