Teltonika TSW304 Gigabit Ethernet (10/100/1000) Network Links PoE Support Black
Teltonika TSW304 Gigabit Ethernet (10/100/1000) Network Links PoE Support Black
Teltonika TSW304 Gigabit Ethernet (10/100/1000) Network Links PoE Support Black
PRICE:
133,99
€
IN A WAREHOUSE
above 10 pcs
We'll ship this product in 6 days.
FREE EUROPE SHIPPING FROM 149 €!
30 DAYS FOR A RETURN!
Sign up and unlock up to 10% off!
- Design
- Product color: Black
- LED diodes
- Status
- Power supply
- DIN rail mounting: Yes
- IP protection class: IP30
- Housing material: Aluminum
- Wall mountable: Yes
- Power
- Voltage: 9 - 40 V
- Power consumption: 0.26 W
- DC input voltage: 7 - 57 V
- Power source: AC/DC
- Power consumption (max): 1.44 W
- Weight and dimensions
- Product weight: 210 g
- Product width: 102 mm
- Product depth: 81.5 mm
- Product height: 25 mm
- Working conditions
- Temperature range (operation): -40 - 75 °C
- Relative humidity range: 10 - 90%
- Network
- Data transfer speed via Ethernet LAN: 10,100,1000 Mbit/s
- Communication standards
- IEEE 802.3
- IEEE 802.3az
- IEEE 802.3u
- Auto MDI/MDI-X: Yes
- 10G Support: No
- Ports and interfaces
- Basic Ethernet switching RJ-45 ports type: Gigabit Ethernet (10/100/1000)
- Basic RJ-45 Switching Number of Ethernet Ports: 4
- Data transfer
- Jumbo Frames Expansion: 9216
- Address table size: 2000 entries
- Jumbo Frame Compatible: Yes
- Routing/switching capacity: 8 Gbit/s
- Packet buffer memory: 0.128 MB
- Power over Ethernet (PoE)
- PoE Support: Yes
- Supported Power over Ethernet (PoE) type: Passive PoE
- Safety warning
- Warnings
- This product is not suitable for disposal in regular trash. Please dispose of used electronic equipment at a recycling center in accordance with local regulations.
- Ensure the device is adequately ventilated during operation.
- Do not open the casing or attempt to repair it yourself.
- Warnings
| Name | Details |
|---|---|
| Producer | Teltonika |
