- Design
- Layout: Rotary
- Product color: White
- Housing material: Plastic
- Mounting type: Ceiling/Desk
- Power
- Power supply type: USB
- DC Output (Volts): 5
- DC Output (Amperes): 1 A
- Weight and dimensions
- Product weight: 200 g
- Product depth: 88 mm
- Product width: 88 mm
- Product height: 100 mm
- Security
- Encryption/Security
- WPA2-PSK
- 128-bit WEP
- WPA
- 64-bit WEP
- WPA-PSK
- WPA2
- Siren noise level: 73 dB
- Intelligent Video Surveillance (IVS) Features: Human Detection
- Privacy Protection: Yes
- Built-in siren: Yes
- Motion sensor: Yes
- Encryption/Security
- Management features
- Reset button: Yes
- Web browser: Yes
- Working conditions
- Temperature range (storage): -40 - 70 °C
- Relative humidity range: 10 - 95%
- Temperature range (operation): -10 - 45 °C
- Permissible relative humidity: 3 - 95%
- Network
- Ethernet interface type: Fast Ethernet
- Wi-Fi standards
- 802.11b
- Wi-Fi 4 (802.11n)
- 802.11g
- Wi-Fi 6 (802.11ax)
- Bluetooth: No
- Wi-Fi: Yes
- Wired LAN: Yes
- Supported network protocols: TCP/IP, UDP, ICMP, HTTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, ARP
- Efficiency
- Model: IP Security Camera
- Connectivity: Wired and wireless
- Intended use: Internal
- Packaging data
- Weight with packaging: 370 g
- Package width: 100 mm
- Package depth: 165 mm
- Package height: 100 mm
- Package contents
- Wires: Alternating Current
- User Manual: Yes
- Number of cameras: 1
- Mounting Brackets Included: Yes
- Audio
- Built-in microphone: Yes
- Sound system: 2-way
- Supported audio formats
- G.711
- G.711u
- AAC
- Built-in speakers: Yes
- Sampling rate: 8 kHz
- Number of built-in microphones: 1
- Data carrier
- Integrated card reader: Yes
- Supported memory cards: MicroSD
- Maximum memory card size: 512 GB
- Built-in HDD: No
- Ports and interfaces
- Number of Ethernet LAN ports (RJ-45): 1
- Camera
- Tilt angle range: -65 - 90°
- Swivel range: 0 - 355°
- Vertical lens angle of view: 51.3°
- Lens viewing angle, diagonal: 90.6°
- Lens angle of view, horizontal: 83.3°
- Number of privacy masking areas: 4
- Photosensitive matrix
- CCD sensor size: 25.4/3 mm (1/3")
- Image sensor type: CMOS
- Night mode
- Night Vision Distance: 10 m
- LED type: Infrared
- Number of lighting diodes: 2
- Night mode: Yes
- Infrared wavelength: 850 nm
- Video
- Maximum resolution: 2880 x 1620 px
- Data flow rate: 512 - 4096
- Digital Dynamic Range (DWDR): Yes
- Total megapixels: 4 MP
- Frame rate: 30 fps
- Compression formats
- H.265
- H.264
- Lens system
- Fixed focal length: 4 mm
- Fixed focus: Yes
- Maximum aperture: 2
