Thermaltake Smart BX1 PS-SPD-0550NNSABE-1 Power Supply (550W; Active; 120mm)
Thermaltake Smart BX1 PS-SPD-0550NNSABE-1 Power Supply (550W; Active; 120mm)
Thermaltake Smart BX1 PS-SPD-0550NNSABE-1 Power Supply (550W; Active; 120mm)
PRICE:
66,99
€
IN A WAREHOUSE
4 pcs
We'll ship this product in 3 days.
FREE EUROPE SHIPPING FROM 149 €!
30 DAYS FOR A RETURN!
Sign up and unlock up to 10% off!
- Design
- Built-in switch: Yes
- Number of fans: 1 fan
- Fan bowl diameter: 12 cm
- Cooling type: Active
- Backlight: No
- Fan Location: Top
- Product color: Black
- Power
- Input current: 10 A
- AC input frequency: 50 Hz
- Total power (+12V): 456 W
- Maximum output current (+5 Vsb): 2.5 A
- Maximum output current (+3.3V): 21 A
- AC input voltage: 230 V
- Total power (+5 Vsb): 12.5 W
- PFC (Power Factor Correction) Type: Active
- Maximum output current (+12V): 38A
- Maximum input current (@ 220V): 10 A
- Total power: 550 W
- Efficiency: 88%
- Maximum output current (+5V): 16A
- Peak power: 660 W
- Good Signal Power Delay Range: 100 - 500 ms
- Maximum output current (-12V): 0.5A
- Total power (+5V): 105 W
- Total power (+3.3V): 105 W
- Hold time: 16 ms
- Total power (-12V): 6 W
- Weight and dimensions
- Product width: 150 mm
- Product height: 86 mm
- Product depth: 140 mm
- Working conditions
- Temperature range (operation): 5 - 40 °C
- Permissible relative humidity: 10 - 95%
- Temperature range (storage): -40 - 55 °C
- Relative humidity range: 20 - 85%
- Efficiency
- Power supply type (PSU): ATX
- Intended use: PC
- EPS version: 2.92
- ATX version: 2.3
- Noise level: 37.6 dB
- Safety: CE, CB, TUV, EAC, RCM
- 80 PLUS Certificate: 80 PLUS Bronze
- MTBF (Mean Time Between Failures): 100000 h
- Ports and interfaces
- Motherboard power connector: 24-pin ATX
- Wiring Type: Non-Modular
- SATA power cable length
- 150
- 500 mm
- Floppy disk drive slot: Yes
- CPU power supply connector (4+4 pin): Yes
- PCI Express slot: Yes
- Motherboard cable length: 60 cm
- PCI Express power connectors (6+2 pin): 2
- Peripheral (Molex) Power Cable Length
- 150
- 500 mm
- Number of SATA power connectors: 6
- CPU power cable length: 65 cm
- Floppy drive connector: 1
- Peripheral (Molex) Power Connectors (4-pin): 4
