THERMALTAKE SMART BX3 550W 80+BRONZE ATX3.1 PCI-E 5.0 SINGLE RAIL DC-DC PS-SPD-0550NNFABE-3
THERMALTAKE SMART BX3 550W 80+BRONZE ATX3.1 PCI-E 5.0 SINGLE RAIL DC-DC PS-SPD-0550NNFABE-3
THERMALTAKE SMART BX3 550W 80+BRONZE ATX3.1 PCI-E 5.0 SINGLE RAIL DC-DC PS-SPD-0550NNFABE-3
PRICE:
69,99
€
IN A WAREHOUSE
3 pcs
Goods available on request - delivery time to 3 working days
FREE EUROPE SHIPPING FROM 149 €!
30 DAYS FOR A RETURN!
Sign up and unlock up to 10% off!
- Design
- Product colour: Black
- Fan diameter: 12 cm
- Power
- Peak power: 550 W
- Maximum output current (+5 V): 18 A
- AC input frequency: 50/60 Hz
- Total power (+5 V): 110 W
- Total power (-12 V): 3.6 W
- AC input voltage: 100–240 V
- Maximum output current (+3.3 V): 18 A
- Total power (+5 Vsb): 15 W
- Input current: 12 A
- Total power (+12 V): 550 W
- Maximum output current (+5 Vsb): 3 A
- Maximum output current (-12 V): 0.3 A
- PFC (Power Factor Correction) type – power factor correction: Active
- Maximum output current (+12 V): 54.2 A
- Hold-up time: 150 ms
- Total power: 550 W
- Total power (+3.3 V): 110 W
- Weight and dimensions
- Product width: 150 mm
- Product height: 86 mm
- Product depth: 140 mm
- Operating conditions
- Temperature range (storage): -40–55 °C
- Temperature range (operation): 5–45 °C
- Permissible relative humidity: 10–95%
- Relative humidity range: 20–85%
- Performance
- Power supply type (PSU): ATX
- Purpose: PC
- 80 PLUS certification: 80 PLUS Bronze
- Silent mode: Yes
- ATX version: 3.1
- Ports and interfaces
- Cabling type: Non-modular
- Safety warning
- Warnings
- Avoid contact between the product and water or other liquids.
- The product must not be disposed of with municipal waste – dispose of it in accordance with local regulations.
- Do not open the housing – risk of electric shock.
