THERMALTAKE TOUGHPOWER PF1 750W FULLY MOD PS-TPD-0750FNFAPE-1
THERMALTAKE TOUGHPOWER PF1 750W FULLY MOD PS-TPD-0750FNFAPE-1
THERMALTAKE TOUGHPOWER PF1 750W FULLY MOD PS-TPD-0750FNFAPE-1
PRICE:
182,99
€
IN A WAREHOUSE
2 pcs
We'll ship this product in 3 days.
FREE EUROPE SHIPPING FROM 149 €!
30 DAYS FOR A RETURN!
Sign up and unlock up to 10% off!
- Design
- Built-in switch: Yes
- Product color: Black
- Fan bowl diameter: 12 cm
- Fan Location: Top
- Number of fans: 1 fan
- Power
- Maximum output current (+3.3V): 20 A
- Input current: 10 A
- AC input voltage: 100 - 240 V
- Peak power: 900 W
- Maximum output current (+5V): 20A
- Total power (+3.3V): 100 W
- Total power (-12V): 3.6 W
- PFC (Power Factor Correction) Type: Active
- Power protection features
- Protection against overvoltage
- Overcurrent
- Total power (+5 Vsb): 12.5 W
- Total power: 850 W
- AC input frequency: 50 - 60 Hz
- Hold time: 16 ms
- Maximum output current (+12V): 62A
- Maximum output current (-12V): 0.3A
- Total power (+12V): 744 W
- Maximum output current (+5 Vsb): 2.5 A
- Weight and dimensions
- Product height: 86 mm
- Product depth: 140 mm
- Product width: 150 mm
- Working conditions
- Temperature range (storage): -40 - 55 °C
- Relative humidity range: 20 - 85%
- Permissible relative humidity: 10 - 95%
- Temperature range (operation): 5 - 50 °C
- Efficiency
- Noise level: 27.8 dB
- Bearing technology: HDB
- MTBF (Mean Time Between Failures): 120000 h
- 80 PLUS Certificate: 80 PLUS Platinum
- Power supply type (PSU): ATX
- Silent mode: Yes
- Package contents
- Cables: AC, Processor, PCIe, Peripheral (Molex), SATA
- Ports and interfaces
- CPU power supply connector (4+4 pin): Yes
- Number of SATA power connectors: 3
- Motherboard cable length: 60 cm
- SATA power cable length
- 500
- 150
- Motherboard power connector: 24-pin ATX
- PCI Express Power (6-pin): 2
- Floppy drive cable length: 15 cm
- PCI Express power connectors (6+2 pin): 4
- CPU power cable length: 65 cm
- Peripheral (Molex) Power Connectors (4-pin): 4
- Peripheral (Molex) Power Cable Length
- 500 mm
- 150
- Floppy disk drive slot: Yes
- Wiring Type: Fully Modular
- Logistics data
- Harmonized System (HS) code: 84733020
| Name | Details |
|---|---|
| Category | Computers and accessories |
| Product Type | Power supplies |
| Producer | Thermaltake |
| Department | Electronics |
