THERMALTAKE TR2 S 600W 80+ SINGLE RAIL DC-DC FLAT CABLES PS-TRS-0600NPCWEU-2
THERMALTAKE TR2 S 600W 80+ SINGLE RAIL DC-DC FLAT CABLES PS-TRS-0600NPCWEU-2
THERMALTAKE TR2 S 600W 80+ SINGLE RAIL DC-DC FLAT CABLES PS-TRS-0600NPCWEU-2
PRICE:
64,99
€
IN A WAREHOUSE
2 pcs
We'll ship this product in 2 days.
FREE EUROPE SHIPPING FROM 149 €!
30 DAYS FOR A RETURN!
Sign up and unlock up to 10% off!
- Design
- Product color: Black
- Fan Location: Top
- Fan speed: 1800
- Fan bowl diameter: 12 cm
- Cooling type: Active
- Number of fans: 1 fan
- Power
- Input current: 8 A
- Total power: 600 W
- Total power (-12V): 6 W
- Efficiency: 86%
- Maximum output current (+12V): 42A
- Total power (+5 Vsb): 12.5 W
- Maximum output current (-12V): 6A
- Maximum output current (+3.3V): 22 A
- AC input voltage: 230 V
- Good Signal Power Delay Range: 100 - 500 ms
- Total power (+5V): 105 W
- AC input frequency: 50 - 60 Hz
- PFC (Power Factor Correction) Type: Active
- Total power (+12V): 504 W
- Maximum output current (+5 Vsb): 12.5 A
- Total power (+3.3V): 105 W
- Hold time: 16 ms
- Maximum output current (+5V): 17A
- Weight and dimensions
- Product depth: 140 mm
- Product width: 86 mm
- Product height: 150 mm
- Working conditions
- Permissible relative humidity: 10 - 95%
- Temperature range (operation): 5 - 40 °C
- Relative humidity range: 20 - 85%
- Temperature range (storage): -40 - 50 °C
- Efficiency
- ATX version: 2.3
- Power supply type (PSU): ATX
- Intended use: PC
- 80 PLUS Certificate: 80 PLUS
- MTBF (Mean Time Between Failures): 100000 h
- Ports and interfaces
- Floppy disk drive slot: Yes
- Motherboard power connector: 20+4 pin ATX
- Wiring Type: Non-Modular
- Peripheral (Molex) Power Connectors (4-pin): 4
- PCI Express power connectors (6+2 pin): 2
- Logistics data
- Harmonized System (HS) code: 84733020
- Safety warning
- Warnings
- Avoid contact of the product with water or other liquids.
- The product is not suitable for disposal with municipal waste – dispose of in accordance with local regulations.
- Do not open the housing – risk of electric shock.
- Warnings
| Name | Details |
|---|---|
| Producer | Thermaltake |
