Trust a brand that cares and always supports its customers.

5-year warranty on the MATE frame
Preferential terms for purchasing components after the warranty period for TOSA customers
Spare parts available immediately from ???? Polish warehouse
The largest Bafang drive system service center in Poland
Custom-designed software for our engines
In the event of a breakdown, we guarantee replacement with a brand new engine – carried out immediately by our authorized partners, without unnecessary formalities.
Let TOSA MATE be more than just a good choice, let it become your best friend during carefree and joyful moments on the bike.

Japanese Carbon - Armored Frame
A frame crafted by enthusiasts—exactly what you expect off-road. The front and rear triangles, as well as the suspension linkage, are crafted entirely from Japanese carbon fiber, resulting in an excellent stiffness-to-weight ratio. Refined geometry and the classic Horst Link suspension system deliver what matters most: stability at high speeds, confident traction on technical sections, and precise handling—regardless of the terrain.

This modern frame, designed specifically for eMTBs, blends form with function. Dynamic lines, a sleekly hidden rear shock, internal cable routing, and a hidden speed sensor ensure a clean look and uncompromising performance. The result? A frame that impresses from the first glance—and even more so when you start riding.

IMG_1499
M510 Engine - The King of Torque and Economy
59 (1)
The Bafang M510 offers a clear advantage where real power and control count. Weighing just 2.9 kg, it offers 250 W of nominal power and 95 Nm of torque, translating into instant acceleration, confident climbing on steep sections, and ample power reserves on challenging terrain. At the same time, it's a true powerhouse: it delivers high torque with low power consumption, making efficient use of the battery and helping extend real-world range. The motor maintains effective support even at high cadences up to 120 RPM, so it doesn't lose performance during fast and dynamic riding. This drive unit combines high operating refinement with premium parameters, making this eMTB confident, faster, and more enjoyable with every kilometer.

Torque 95 Nm
Peak power 800 W

Battery - capacity and economy
A powerful main battery and the option to add a Range Extender transform this bike into a true eMTB ultramarathoner. The additional battery configuration provides a total of 1200 Wh of energy—800 Wh in the main battery plus 400 Wh in the Range Extender—giving you significantly more time in the mountains, longer rides, and less range anxiety. The battery has been completely redesigned and is embedded in the frame to minimize contact with moisture, while a refined sealing system allows for trouble-free riding in challenging, rainy conditions. The new battery shape, based on the latest cell technology, allows for a longer and slimmer battery, resulting in a lower and narrower downtube, and a cleaner, more streamlined overall bike.

Main battery
800Wh

Range Extender
400 Wh

TOSA offers a wide range of configuration options for the MATE model. A major advantage is the option to choose from a variety of packages that can be tailored to each user's individual preferences.

Additionally, you can choose individual components or accessories. We leave the decision up to the user, ensuring that each MATE is unique and unrepeatable.

The MATE impresses on many levels. Thanks to its precise frame design and minimalistic details, it stands out in every aspect.

Its clean and uncluttered cockpit, minimal cables and levers, along with an internal cable routing system that smoothly passes through dedicated holes in the headset, with a special rubber seal. All this makes the cockpit a reliable companion that doesn't distract, but rather supports every moment of focused cycling.

Cable integration and ergonomic routing, supported by dedicated covers, ensure that you don't have to worry about anything else while riding than the pure pleasure of pedaling.

The MATE is the result of the work of many passionate enthusiasts who determinedly strived to create the perfect product. The suspension, which works incredibly well on descents, retains its exceptional sensitivity and reacts to the slightest bumps.

Engine
• Bafang M510 36V, Gear Drive
• Power 250 W
• Torque 95 Nm
• Speed and pressure sensor

Battery
• Capacity 22.28Ah 800Wh
• Produced in Europe
• Removable from the bottom of the frame
• Lockable, two keys included
• 4A fast charger

Frame
• Full Carbon, with internal cable routing (carbon cable)
• High-quality carbon fiber frame
• Frame travel 150 mm
• 12 × 148 mm Boost, Thru-Axle
• Tapered head tube with a set of reinforced aluminum bearings

Fork
• RockShox 35 Gold
• 29” Boost
• Steerer tube 1 1/8”–1 1/2”
• 150 mm stroke
• Application and operating characteristics specifically for eBikes
• 15 × 110 Boost
• Black varnish

Hoops
• TOSA ALLM35 HD (Heavy Duty)
• Mullet: 29” front rim, 27.5” rear rim
• Wide and durable rims for eMTB
• Tubeless Ready
• Aluminum, black painted

Tires
• Michelin E-Wild
• Tubeless Ready
• E-GUM X technology
• Gravity Shield

Rear shock absorber
• RockShox Deluxe Select DebonAir
• Nominal size 210 × 55 mm
• Adjustment: compression and rebound
• Black varnish

Brakes
• Magura MT5 PRO
• HC aluminum one-finger brake lever
• Adjustable handle reach setting
• Four-piston aluminum caliper
• Made in Germany

Drive
• Rear derailleur Shimano Deore RD-M5100, Shadow+, Dyna-SYS11
• Shimano Deore SL-M5100 shifter
• KMC E.11 chain in EPT version
• Sunrace CSMS8 cassette, 11–51T range, steel, for eMTB
• Bafang Narrow Wide EB02 32T Crankset

Cockpit
• TOSA ALLM steering wheel 35 × 780 mm, black painted
• TOSA ALLM35 35mm bridge, black lacquered
Saddle and seat post
• TOSA ALLM saddle, black
• TOSA ALLM150 adjustable seatpost with handlebar-mounted shifter
• 150 mm travel

Libra
• Bike weight ~23.6 kg

TOSA brand products meet the strict European Union standards for electric bicycles: EN15194 / EPAC / ISO4210-2
