TP-Link Deco X20-4G Dual-band (2.4 GHz/5 GHz) Wi-Fi 6 (802.11ax) White 3 3G, 4G Internal
TP-Link Deco X20-4G Dual-band (2.4 GHz/5 GHz) Wi-Fi 6 (802.11ax) White 3 3G, 4G Internal
Sign up and unlock up to 10% off!
- Characteristics
- Quality of Service (QoS) Support: Yes
- Number of processor cores: 4
- ALTHOUGH: Yes
- Processor clock speed: 1.5 GHz
- Smart mesh technology: Yes
- Operating modes: 3G/4G, Router, Access Point
- Cloud system support: TP-Link ID
- Built-in processor: Yes
- Port Forwarding: Yes
- Design
- Product color: White
- Antenna type: Internal
- Number of antennas: 4
- LEDs: Power
- Reset button: Yes
- Transmit power: CE: ≤20 dBm (2.4GHz), ≤23 dBm (5GHz)
- Number of supported devices: 150
- Power
- AC input voltage: 100 - 240 V
- AC input frequency: 50/60 Hz
- AC adapter output current: 1.5 A
- AC adapter output voltage: 12V
- Power supply input current: 0.6 A
- Weight and dimensions
- Product depth: 105 mm
- Product height: 167 mm
- Product width: 105 mm
- Working conditions
- Permissible relative humidity: 5 - 90%
- Temperature range (operation): 0 - 40 °C
- Temperature range (storage): -40 - 60 °C
- Relative humidity range: 10 - 90%
- Packaging data
- Package depth: 213.5 mm
- Weight with packaging: 1.22 kg
- Package width: 241 mm
- Package height: 124 mm
- Package contents
- Number of devices in the set: 1 pc.
- AC adapter: Yes
- Number of products included: 1 pc.
- Ethernet cable: Yes
- Wireless LAN Features
- Communication standards
- IEEE 802.11b
- IEEE 802.11n
- IEEE 802.11g
- IEEE 802.11ax
- IEEE 802.11a
- IEEE 802.11ac
- Encryption/Security
- WPA-PSK
- WPA
- WPA3
- Basic Wi-Fi standard: Wi-Fi 6 (802.11ax)
- Wi-Fi standards
- 802.11b
- 802.11g
- 802.11a
- Wi-Fi 4 (802.11n)
- Wi-Fi 5 (802.11ac)
- Wi-Fi 6 (802.11ax)
- Point-to-point protocol over Ethernet (PPPoE): Yes
- Number of guest networks (5 GHz): 1
- Number of guest networks (2.4 GHz): 1
- Guest Access: Yes
- WLAN data transfer rate (first band): 574 Mbit/s
- Static IP: Yes
- Dynamic IP address: Yes
- Dynamic DNS (DDNS): Yes
- Wi-Fi frequency: Dual-band (2.4 GHz/5 GHz)
- WLAN data transfer rate (second band): 1201 Mbit/s
- Communication standards
- Protocols
- Supported network protocols (IPv6): Y
- Ports and interfaces
- DC output socket: Yes
- Number of Ethernet LAN ports (RJ-45): 3
- Ethernet WAN: Yes
- Logistics data
- Harmonized System (HS) code: 85171800
- Mobile network
- Supported 4G networks
- 1800 MHz
- 850 MHz
- 2100 MHz
- 700 MHz
- 800 MHz
- 2300 MHz
- 2600 MHz
- 2500 MHz
- 900 MHz
- Supported UMTS bands
- 900
- 850
- 2100 MHz
- 3G standards
- UMTS
- DC-HSPA+
- HSPA
- 4G standards: TD-LTE & FDD-LTE
- SIM card type: NanoSIM
- Mobile network generation: 3G, 4G
- Supported 4G networks
| Name | Details |
|---|---|
| Producer | TP-LINK |
