TP-Link JetStream TL-SG3428XPP-M2 Network Switch Managed L2+ 2.5G Ethernet (100/1000/2500) Supports PoE 1U Black
TP-Link JetStream TL-SG3428XPP-M2 Network Switch Managed L2+ 2.5G Ethernet (100/1000/2500) Supports PoE 1U Black
TP-Link JetStream TL-SG3428XPP-M2 Network Switch Managed L2+ 2.5G Ethernet (100/1000/2500) Supports PoE 1U Black
PRICE:
1775,99
€
IN A WAREHOUSE
LAST ITEM!
We'll ship this product in 5 days.
FREE EUROPE SHIPPING FROM 149 €!
30 DAYS FOR A RETURN!
Sign up and unlock up to 10% off!
- Design
- Layout: 1U
- Rack mounting options: Yes
- LEDs: Yes
- Product color: Black
- Number of fans: 3 fans
- Redundant Fan Support: Yes
- Power
- Power source: AC/PoE
- AC input frequency: 50/60 Hz
- Backup Power Supply (RPS) Support: Yes
- AC input voltage: 100 - 240 V
- Power supply included: Yes
- Power consumption (max): 629.1 W
- Weight and dimensions
- Product depth: 330 mm
- Product height: 44 mm
- Product width: 440 mm
- Security
- Encryption/Security
- SSH-2
- HTTPS
- SSL/TLS
- SSH
- Password protection: Yes
- DHCP functions
- DHCP server
- DHCPv6 snooping
- DHCP relay
- DHCP snooping
- DHCP client
- DHCPv6 client
- Loop protection: Yes
- Access Control List (ACL): Yes
- IGMP snooping: Yes
- Authentication: Guest VLAN, MAC-based authentication, Port-based authentication
- Static Port Protection: Yes
- Queue planning algorithms
- SP
- WRR+SP
- Weighted Round Robin (WRR)
- BPDU Filtering/Protection: Yes
- Supports SSH/SSL: Yes
- Authentication type: AAA, IEEE 802.1x, RADIUS, TACACS+
- IP-MAC-Port Binding: Yes
- Encryption/Security
- Management features
- Website management: Yes
- Quality of Service (QoS) Support: Yes
- Switch type: Managed
- Switch Layer: L2+
- System Event Report: Yes
- MIB support: RFC1213, RFC2233, RFC1643, RFC1493, RFC2674, RFC2819, RFC2021, RFC2620, RFC2618, RFC2925
- Cloud-managed: Yes
- Configuring Location Settings (CLI): Yes
- ARP Inspection: Yes
- Working conditions
- Relative humidity range: 10 - 90%
- Temperature range (storage): -40 - 70 °C
- Permissible relative humidity: 5 - 90%
- Temperature range (operation): 0 - 40 °C
- Heat emission: 2153.45 BTU/h
- Network
- VLAN support: Yes
- Communication standards
- IEEE 802.3at
- IEEE 802.3ad
- IEEE 802.1p
- IEEE 802.3af
- IEEE 802.3x
- IEEE 802.1Q
- IEEE 802.1D
- IEEE 802.3
- IEEE 802.1x
- IEEE 802.1s
- IEEE 802.3ab
- IEEE 802.3ae
- IEEE 802.1ab
- IEEE 802.3bz
- IEEE 802.3bt
- IEEE 802.3z
- IEEE 802.3u
- IEEE 802.1w
- Full duplex: Yes
- Data transfer speed via Ethernet LAN: 10,100,1000,2500,10000 Mbit/s
- 10G Support: Yes
- Virtual LAN Features
- Tagged VLAN
- Voice VLAN
- Port-based VLAN
- Stacked VLAN
- MAC address-based VLAN
- Protocol-based VLAN
- Connection Aggregator: Yes
- Traffic Growth Control: Yes
- Flow Control Support: Yes
- Port Mirroring: Yes
- Spanning Tree Protocol: Yes
- Frequency Limit: Yes
- IPv4 routes: 48
- IPv6 routes: 48
- Half-duplex: Yes
- Head-of-line (HOL) blocking: Yes
- Efficiency
- Flash memory size: 32 MB
- Memory type: DRAM
- Internal memory capacity: 256 MB
- Packaging data
- Weight with packaging: 6.1 kg
- Package height: 100 mm
- Package width: 528 mm
- Package depth: 440 mm
- Package contents
- Wires: Alternating Current
- Quick Start Guide: Yes
- Hook mounting kit: Yes
- Certificates
- Certificates of conformity
- RoHS
- CE
- Federal Communications Commission (FCC)
- Certificates of conformity
- Protocols
- Management protocols: SNMP v1/v2c/v3
- IPv4 and IPv6 features
- IPv6 tracert
- IPv6 portal
- IPv6 ping
- IPv4/IPv6 access-control list (ACL)
- GARP VLAN Registration Protocol (GVRP): Yes
- Ports and interfaces
- Number of SFP+ Module slots: 4
- Basic Ethernet Switching RJ-45 ports type: 2.5G Ethernet (100/1000/2500)
- Number of 2.5G Ethernet ports (copper): 24
- Console Port: RJ-45/Micro-USB
- Basic RJ-45 Switching Number of Ethernet Ports: 24
- Data transfer
- Routing/switching capacity: 200 Gbit/s
- Jumbo Frame Compatible: Yes
- Address table size: 32000 entries
- Static Route: Yes
- Number of rounds: 8
- Packet buffer memory: 16 MB
- Number of static routes: 48
- Jumbo Frames Expansion: 9000
- Transfer speed: 148.8 Mpps
- Store-and-forward: Yes
- Number of IP interfaces: 32
- Power over Ethernet (PoE)
- Total Power over Ethernet (PoE) budget: 500 W
- PoE Support: Yes
- Number of Power over Ethernet 4PPoE (PoE++) ports: 8
- Power over Ethernet Plus (PoE +) ports: 16
- Multicast functions
- Multicast Support: Yes
- Multicast Listener Discovery (MLD) snooping: MLD v1/v2
- Sustainable development
- Sustainability: Yes
