TP-Link Omada EAP683 UR WLAN access point 6000 Mbit/s White PoE support
TP-Link Omada EAP683 UR WLAN access point 6000 Mbit/s White PoE support
Sign up and unlock up to 10% off!
- Characteristics
- 6GHz: No
- Frequency band: 2.4 - 6 GHz
- 5GHz: Yes
- Communication standards
- IEEE 802.3at
- IEEE 802.11a
- IEEE 802.11ax
- IEEE 802.11g
- IEEE 802.11ac
- IEEE 802.11b
- IEEE 802.11n
- Data transfer speed via Ethernet LAN
- 10 Mbps
- 100 Mbps
- 1000 Mbps
- 2500 Mbps
- ALTHOUGH: Yes
- BeamForming: Yes
- 2.4GHz: Yes
- Maximum data transfer speed: 6000 Mbit/s
- Maximum data transfer rate (5 GHz): 4804 Mbit/s
- Automatic channel selection: Yes
- Band Control: Yes
- Fast roaming: Yes
- Maximum data transfer rate (2.4 GHz): 1148 Mbit/s
- Frequency Limit: Yes
- Quality of Service (QoS) Support: Yes
- Automatic Channel Scan: Yes
- Airtime Fairness (ATF): Yes
- MIMO Type: Multi User MIMO
- VLAN support: Yes
- Number of users: 510 users
- Design
- LEDs: Yes
- Reset button: Yes
- Product color: White
- Intended use: Ceiling, Wall
- Power
- PoE Support: Yes
- DC voltage range: 12V
- Weight and dimensions
- Product height: 32.5 mm
- Product width: 220 mm
- Product depth: 220 mm
- Security
- MAC address filtering: Yes
- Encryption/Security
- SSH
- HTTPS
- SNMPv2
- SNMP
- SNMPv3
- Service Set Identifier (SSID) Features: Multiple SSIDs
- Access Control List (ACL): Yes
- Management features
- Device software updates: Yes
- Syslog: Yes
- Working conditions
- Temperature range (storage): -40 - 70 °C
- Temperature range (operation): 0 - 40 °C
- Permissible relative humidity: 5 - 90%
- Relative humidity range: 10 - 90%
- Packaging data
- Packaging type: Box
- Package contents
- Quick Start Guide: Yes
- Mounting kit: Yes
- Number of pieces: 1
- Ports and interfaces
- DC output socket: Yes
- Number of Ethernet LAN ports (RJ-45): 1
- Antenna
- Antenna type: Internal
- Antenna gain level (max): 5 dBi
- Antenna Direction Type: Omnidirectional Antenna
| Name | Details |
|---|---|
| Producer | TP-LINK |
