TP-LINK TL-ER605 router
TP-LINK TL-ER605 router
Sign up and unlock up to 10% off!
- Characteristics
- Supported Windows operating systems
- Windows 8.1
- Windows XP
- Windows 2000
- Windows 98SE
- Windows 10
- Windows Vista
- Windows NT
- Windows 8
- Windows 7
- RAM type: DRAM
- Linux operating systems supported: Yes
- Flash memory size: 128 MB
- Internal memory capacity: 256 MB
- Supported Mac operating systems: macOS
- Supported Windows operating systems
- Design
- LED diodes
- Action
- USB
- WAN
- LAN
- System
- Product color: Black
- Rack capacity: 1U
- Rack mounting options: Yes
- Flash memory size: 16 MB
- Built-in DRAM (eDRAM) memory: 128 MB
- LED diodes
- Power
- AC input voltage: 120 - 240 V
- Power supply type: AC
- AC input frequency: 50 - 60 Hz
- Power consumption: 7.94 W
- Weight and dimensions
- Product width: 158 mm
- Product depth: 101 mm
- Product height: 25 mm
- Security
- Network Address Translation (NAT): Yes
- Encryption/Security
- 128-bit AES
- 192-bit AES
- 3DES
- DES
- MD5
- 256-bit AES
- SHA-1
- URL Filtering: Yes
- DoS attack prevention: Yes
- Number of VPN tunnels: 20
- System Event Report: Yes
- Authentication method: SHA-1, MD5
- Firewall: Yes
- ARP Attack Prevention: Yes
- Management features
- Website management: Yes
- Reset button: Yes
- Universal Plug and Play (UPnP): Yes
- Working conditions
- Permissible relative humidity: 5 - 90%
- Temperature range (operation): 0 - 40 °C
- Temperature range (storage): -40 - 70 °C
- Relative humidity range: 10 - 90%
- Network
- Data transfer speed via Ethernet LAN
- 10 Mbps
- 100 Mbps
- 1000 Mbps
- Communication standards
- IEEE 802.3ab
- IEEE 802.3
- IEEE 802.1Q
- IEEE 802.3x
- IEEE 802.3u
- VLAN support: Yes
- Ethernet interface type: Gigabit Ethernet
- Motion control: Yes
- Concurrent connections: 150000
- Cabling technology: 10/100/1000Base-T(X)
- Rule-Based Routing: Yes
- Data transfer speed via Ethernet LAN
- Packaging data
- Weight with packaging: 650 g
- Package width: 190 mm
- Package height: 60 mm
- Package depth: 254 mm
- Package contents
- Quick Start Guide: Yes
- Quick Installation Guide: Yes
- Wires: Alternating Current
- User Manual: Yes
- Certificates
- Certificates of conformity: RoHS
- Protocols
- DHCP Client: Yes
- Route Selection Protocol
- RIP-1
- RIP-2
- Management Protocols: Telnet
- DHCP server: Yes
- DMZ Support: Yes
- Supported network protocols: TCP/IP, DHCP, ICMP, NAT, PPPoE, SNTP, HTTP, DNS, IPsec, PPTP, L2TP
- Ports and interfaces
- Number of Ethernet LAN ports (RJ-45): 5
- Number of USB ports: 1
- WAN connection
- Ethernet WAN: Yes
- USB 3G/4G Connection: No
- DSL WAN: No
- SIM card slot: No
- Safety warning
- Warnings
- The product may emit radio waves that may interfere with the operation of other electronic devices.
- Do not open the device casing - risk of electric shock.
- Avoid contact with liquids as this may cause electric shock.
- Warnings
| Name | Details |
|---|---|
| Producer | TP-LINK |
