TRENDnet TI-F10S30 – Media converter – Ethernet, Fast Ethernet – 10Base-T, 100Base-FX, 100Base-TX – RJ-45 / single-mode SC – up to 30 km – 1310 nm
TRENDnet TI-F10S30 – Media converter – Ethernet, Fast Ethernet – 10Base-T, 100Base-FX, 100Base-TX – RJ-45 / single-mode SC – up to 30 km – 1310 nm
TRENDnet TI-F10S30 – Media converter – Ethernet, Fast Ethernet – 10Base-T, 100Base-FX, 100Base-TX – RJ-45 / single-mode SC – up to 30 km – 1310 nm
PRICE:
98,99
€
IN A WAREHOUSE
4 pcs
We'll ship this product in 9 days.
FREE EUROPE SHIPPING FROM 149 €!
30 DAYS FOR A RETURN!
Sign up and unlock up to 10% off!
- Features
- International Protection (IP) code: IP40
- LED indicators: Yes
- Housing material: Metal
- Product colour: Black
- Internal: No
- DIN rail mounting: Yes
- Power
- Voltage: 12–60 V
- Power consumption (max): 1.92 W
- Weight and dimensions
- Product depth: 50 mm
- Product width: 60 mm
- Product height: 35 mm
- Product weight: 90 g
- Operating conditions
- Operating temperature range: -40–75 °C
- Network
- Ethernet network interface type: Fast Ethernet
- Ethernet LAN data transfer rate
- 100 Mbit/s
- 10 Mbit/s
- Communication standards
- IEEE 802.3u
- IEEE 802.3
- IEEE 802.3x
- Maximum data transfer rate: 200 Mbit/s
- Duplex transmission
- Half-duplex
- Full-duplex
- Fibre Ethernet cabling technology: 100BASE-FX
- Flow control support: Yes
- Copper Ethernet cabling technology
- 10BASE-T
- 100BASE-TX
- Output interface converter: 100Base-TX
- Auto-negotiation: Yes
- Input interface converter: 100Base-FX
- Performance
- Maximum transfer distance: 30000 m
- Supported fibre optic cable diameter: 9/125 µm
- Single-mode fibre structure: Single
- Wavelength: 1310 nm
- Link budget: 7 dB
- Packaging content
- Quick installation guide: Yes
- Ports and interfaces
- Connectivity technology: Wired
- Number of Ethernet LAN (RJ-45) ports: 1
- Number of ports: 1
- Fibre optic connector: SC
- Logistics data
- Harmonized System (HS) code: 85176990
| Name | Details |
|---|---|
| Department | Electronics |
| Product Type | Network switches |
| Producer | No name |
