VIGI 4 CHANNEL NETWORK RECORDER/NVR
VIGI 4 CHANNEL NETWORK RECORDER/NVR
Sign up and unlock up to 10% off!
- Characteristics
- Reset button: Yes
- Product color: Black
- LEDs: Yes
- Power
- Power consumption: 4.25 W
- Weight and dimensions
- Product weight: 590 g
- Product depth: 148.2 mm
- Product height: 45 mm
- Weight with packaging: 950 g
- Product width: 246.2 mm
- Working conditions
- Temperature range (storage): -40 - 70 °C
- Temperature range (operation): -10 - 55 °C
- Relative humidity range: 10 - 90%
- Permissible relative humidity: 10 - 90%
- System requirements
- Supported browsers: Chrome (57+), Firefox (52+), Edge (91+)
- Support for mobile operating systems
- iOS
- Android
- Efficiency
- Video channel inputs: 4 channels
- Video recording modes
- 1080p
- 2160p
- 720p
- Supported video file formats
- H.265
- H.265+
- H.264+
- H.264
- Output bandwidth: 60 Mbit/s
- Input bandwidth: 80 Mbit/s
- Backup function: Yes
- Supported audio formats
- G.711u
- G.726
- Maximum resolution: 3840 x 2160 px
- Resolution at capture speed
- 3840x2160@30fps
- 1280x720@60fps
- 1920x1080@60fps
- Video motion detection: Yes
- Recording Mode: Manual, Schedule
- Maximum frame rate: 30 fps
- Package contents
- Quick Installation Guide: Yes
- AC adapter: Yes
- Wireless LAN Features
- Wi-Fi: No
- Ports and interfaces
- DC output socket: Yes
- Number of HDMI ports: 1
- Supported network protocols: UPnP (Plug and Play), NTP (Network Timing)
- HDMI output: Yes
- RCA audio connectors: 1
- Number of USB 2.0 ports: 2
- VGA (D-Sub) Outputs: 1
- Number of Fast Ethernet (PoE) ports: 1
- RCA audio outputs: 1
- Number of Ethernet LAN ports (RJ-45): 1
- Hard drive
- Maximum storage capacity: 10 TB
- HDD capacity: 0 GB
- HDD interface: SATA
- Safety warning
- Warnings
- The device should be installed by a qualified specialist.
- Do not expose the device to moisture or extreme temperatures.
- The product must be disposed of properly in accordance with local regulations for electronics disposal.
- Warnings
| Name | Details |
|---|---|
| Category | Industry |
| Producer | TP-LINK |
